6. Insertion of the glazing
6.2 Sliding leaf installation
6.2.1
Wrap two small aluminum sheets with tape and place
them onto the lower outer frame.
6.2.2
Insert sliding leaf into the upper outer frame first, then
place it onto the two aluminum sheets on the lower outer
frame.
6.2.3
Insert roller carriages.
