Keller minimal windows

4+ 06

8mm

On-site installation | 997-000120 | 07-2021

6. Insertion of the glazing

6.2 Sliding leaf installation

6.2.4

Lift sliding leaf and remove aluminum sheets.

Then, place element onto sliding rail.

6.2.5

Underlay handle bars and junction proﬁles with 8 mm

spacers, then snap on to sliding leaf and screw.

8 mm spacing is

the system requirement
