Page 18

6.DIAGRAMS

6.1 AIR FLOW DIAGRAMS

KRAD 15M - KRAD 25M

REFRIGERANT GAS FLOW

1

COMPRESSED AIR FLOW

DRAIN FLOW

M

2

AIR INLET

AIR OUTLET

S

3

4

5

6

7

8

DESCRIPTION

POS.

QTY

1

2

3

4

5

6

7

8

9

10

11

COMPRESSOR 1

1

1

1

FAN MOTOR

FAN SWITCH

FILTER

FILTER DRYER

1

1

1

2

1

1

EXPANSION VALVE

HEAT EXCHANGER

SOLENOID VALVE

CONDENSER

FILTERED DRAIN

9

11

10

2CHECK VALVE

10
