9. COMPONENTS LOCATION
All main components located into dryer identified with labels as listed here under.
CAUTION: Due to manufacture design, some components out of the list are not installed into the dryer.
Electrical components:
Accessories :
A01: Control circuit transformer
A02: Power circuit transformer
A10: ON warning light
A11: OFF warning light
A20: Drain solenoid valve
A30: Cranckase heater
A31: Electrical resistor
A40: Electrical capacity
EV3 Digital Controller (Digi-Pro)
A50-3: Energy saving device 3 (ESD3)
Relays :
K01: Compressor motor relay
K10: Fan motor relay
K20: Drain timer or Bekomat (optional)
K30: Temperature Controller
Switches :
S01: Main switch
S02: Start push button
S03: Stop push button
S10: Fan pressure control
S11: High-low pressure security control
S12: High pressure security control
S13: Low pressure security control
S20: Refrigerant temperature control
S21: Air temperature control
Motors :
M01: Refrigerant compressor motor
M10: Fan motor
Thermal protections :
P01: Refrigerant compressor thermal overload
P10: Fan motor thermal overload
Fuses protections :
See complete identification into electrical sketch included in dryer
F--: Transformer protection
F--: Fan protection
F--: Compressor relay protection
F--: Transformer protection
F--: Drain protection
F--: Fan relay protection
Refrigerant components:
G01: Liquid receiver
G02: Refrigerant drier
G03: Expansion valve
G04: Liquid separator
G05: Hot gas bypass valve
G06: Refrigerant solenoid valve
G10: Water cooled condenser
G11: Water control valve
G20: Refrigerant evaporating pressure gauge
G21: Refrigerant evaporating temperature gauge
Compressed air components :
H01: Air inlet prefilter
H11: Drain filter
H12: Pneumatic drain valve
Terminal boxes:
B01: Main terminal box
B11: Refrigeranbt unit termal box
B12: Free of potential terminal box
