Keltech KRAD M Series - General Arrangements; Model and Replacement Kit Overview; General Model Specifications

Page 37
Model
Replacement Kits
Control
Type
Length
(mm)
Width
(mm)
Height
(mm)
Weight
(kg)
KRAD 15M
ADFK1-REV3
DigiPro 372 369 706 32
KRAD 25M
ADFK1-REV3
DigiPro 372 369 706 32
KRAD 40M
ADFK2-REV1
DigiPro 454 473 832 51
KRAD 60M
ADFK2-REV1
DigiPro 454 473 832 53
KRAD 80M
ADFK2-REV1
DigiPro 454 473 832 55
KRAD 100M
ADFK3-REV1
DigiPro 506 556 875 78
KRAD 125M
ADFK3-REV1
DigiPro 506 556 875 83
KRAD 150M
ADFK3-REV1
DigiPro 506 556 875 86
KRAD 200M
ADFK4-REV1
DigiPro 648 678 1157 160
KRAD 250M
ADFK4-REV1
DigiPro 648 678 1157 165
7.GENERAL ARRANGEMENTS
ALL MODELS Superheat of
thermostatic
expansion
valve
Evaporating
pressure
Fan
pressure
switch
Security
high
pressure
switch
Security
low
pressure
switch
Drain
timer
Refrigerant
temperature
switch
Water flow
valve
(if water
condenser)
5°C - 10°C 2.05 bar 9 - 12 bar 25 bar 1.6 bar 5 min. -5sec. 45°C 11 bar
