KEM ECO - Getting Started; Unpacking and Verification; Ordering Elements Overview

7
Getting started
Version: ECO_M_ENG_220303_E001
2.1.4. Accessories
Ordering Code Description
ECO-COM.B.USB: Interface adapter: KEM interface to USB. When communicating via ECO-COM.USB.B,
the ECO is supplied with voltage via the USB interface. The output functionalities are
not available during configuration.
KEM EcoControl: P Parameterization software for WINDOWS®. The minimum installation requirements:
Windows 10.
3. Getting started
3.1. Unpacking
Verify that you have received the following items:
When you ordered ECO:
• ECO
• User’s manual
• Conformation declaration (EU)
When you ordered ECO-COM.B.USB:
• ECO-COM.B.USB
• USB 2.0 cable A/B 1,5m
• CD with KEM EcoControl Software an USB drivers
3.2. Ordering Elements
3.2.1. ECO
Fig. 1: ECO controls
1 = Connector plug
2 = Sensor tip
3 = Screw tap M14 thread
4 = Pickup tip
2
4
1
3
