SERVICE MANUAL
FASTMIG X
24 (37)
Kemppi OY
3. MEMORY CARD A003
Memory card is connected to motor control card A001
Flash memory is programmed in Kemppi production line
3.1. Connectors
Connector Description
X1:1 -
X1:2 -
X1:3 -
X1:4 -
X1:5 +3.3V
X1:6 GND
4. TACHO CARD A004
Hall-effect sensor IC N1 is used on rotary encoder card. Sensor generates tacho-pulses when motor’s magnetic ring
attached to motor’s gearing is rotating close the sensor. Generated tacho-pulses are measured by motor control card
A001 microcontroller and motor’s speed of rotation can be calculated
4.1. Connectors
Connector Description
X1 +5V
X2 GND
X3 Tacho signal
4. PANEL CARD P001
Panel card is connected to the motor control card A001 with 16-wire ribbon cable
4.1. Connectors
Connector Description
X1:1 Remote pot WFS
X1:2 Remote pot U
X1:3 Gas guard
X1:4 Torch lines
X1:5 SubAd /MXF_id
X1:6 Motor current
X1:7 GND
X1:8 Gas valve on
X1:9 Tacho signal
X1:10 Mux start/gun pot
X1:11 Can data
X1:12 Can rxd
X1:13 can txd
X1:14 + 9 V
X1:15 + 5 V
X1:16 GND
X15:6 System bus GND
X16:1 Secondary voltage+
X16:2 Secondary voltage-
X16:3 Secondary voltage fused-
X16:4 Secondary voltage fused+
X16:5 Not connected
X16:6 Not connected
X19:1 Gas guard (+)
X19:2 Gas guard (-)
