Kemppi Mastercool 30 - Technical Information; Technical Data; Wiring Diagram

Service manual Mastercool 30 Version 1.0 1.11.2011
3
Kemppi Oy
3. TECHNICAL INFORMATION
3.1. Technical data
Mastercool 30
Operating voltage 24VDC
Cooling power 1.0 kW
Connection capacity 100% ED 50W
Maximum pressure 4.0 bar
100 % ED I
eff1
12.9 A
Cooling liquid 20% - 40% glycol-water
Tank volume Approx. 3 l
External dimensions LxWxH 500x180x260mm
Weight 8 Kg
3.2. Wiring diagram
