3.3.1. Inner structure
1. Fastening points to power source
2. Hot water/return snap connector (red)
3. Cool water/output snap connector (blue)
4. Hydrocool pump
5. A001 control card
6. Water tank filling hose
7. Water tank
8. Cooling fan
9. Radiator (inside the chassis)
1.
4.
5.
3.
2.
6.
7.
9.
8.
