Control card A001
Jumper functions (jumper block X7)
765
X7
8 9101 2 3 4
Gas/Water cooled gun selection switch by-
passing (always in water position).
Gas/Water cooled gun selection switch by-
passing (selection controlled by Gas/Water
selection switch).
765 8 9103 4
Output is linear according to potentiometer
turning angle.
Output is linear according to control voltage:
Wire feeding: 0- 5V ⇒ 0 - 18, 25m/min.
Voltage: 0- 5V ⇒ 0 - 50V.
765
X7
8 9101 2
3
4
X7
1 2
765 8 9103
4
X7
1 2
765 8 9103 4
PMT and RMT 10 additional properties NOT
in operation (Err 11).
X7
1 2
76
5
8 9103 4
X7
1 2
PMT and RMT 10 additional properties in
operation.
