REFRIGERATOR INSTALLATION
FREEZER DOOR REMOVAL
1. Separate the cap on the middle hinge.
2. After removing one screw and two bolts, remove
the middle hinge. (Unscrew the screws with the
screwdriver (+) and hex bolts with the 3/16-in. [4.75-mm]
hex wrench.)
Middle Hinge
3a. Remove the middle hinge from the top of the freezer
door.
3b. Remove the freezer door by lifting it upward.
Be careful not to drop or scratch the freezer door.
4. Remove the cap on the bottom hinge.
NOTE: The bottom hinge cap can come off with the freezer
door.
WARNING
Be careful not to drop the freezer door during removal.
Scratches or door damage could occur.
To Next Page
