5. HOW TO CONTROL THE AMOUNT OF
WATER SUPPLIED TO ICE MAKER
2) Turn on the electricity after connecting water pipe.
1) Press the test switch under the icemaker for two seconds as
shown below.
2) The bell rings (ding ~ dong), the ice tray rotates, and water
comes out the icemaker water tube.
3) The water is supplied into the tray two or three times. The
amount is small each time. Put a container under the ice tray
and press test switch.
4) When the ice tray rotates, the water in it will spill. Collect the
spilled water and discard it.
5) When ice tray has finished rotation, water comes out the
water tube. Check the amount that goes into the ice tray.
(Refer to the drawing below. The optimum amount is 110cc.
(Almost 4 oz.)).
* It is acceptable is the adjusted water level is less than the
optimum level.
• To assemble the ice storage bin, lift it while
slightly push it out .
NOTE: Use both hands to remove the ice bin to avoid
dropping it. If the ice bin does not slide into place easily,
twist the drive device slightly.
• Hold the ice storage bin as shown in the figure
and pull it out .
1. DISASSEMBLY ICE STORAGE BIN
1
2
2. DISASSEMBLY ICEMAKER
If you need acces to the Icemaker, follow these steps:
• Lift the ice shelf and pull it out .
COVER
Feeler Arm
Power Switch
ON/OFF
(On the lower
part of icemaker)
switch
Test
- 10 -
NOTE Make sure the bin is fully engaged into the auger
drive . If not, rotate the auger drive in the direction
shown by the arrow until they bin is fully engaged into the
auger drive.
:
1
2
To Next Page
