- 7 -
1. Remove gasket
Pull gasket free from gasket channel on the four
remaining sides of door.
3-2 DOOR
●
Pillar Removal
1. Remove 2 screws.
●
Door Gasket Removal
2. Lift pillar up carefully.
3. Disconnect wire harness.
●
Door Gasket Replacement
1. Insert gasket into channel
Press gasket into channels on the four remaining
sides of door.
2. Insert pillar into channel.
Inserting pillar assy’ into bracket, door
●
Pillar Replacement
1. Connect wire harness.
3. Assemble 2 screws.
To Next Page
