13
Induction Cooking Zones
The cooking zone sensors located below the cooktop
surface require that certain cookware conditions are met
before the induction cooking zones can operate. Be sure to
check that the cookware has met all the correct conditions
listed in Fig. 2. Use this checklist as a guide to help to
correct the problem or problems before attempting to
reactivate cooking zones.
Pan sensing
The cooking zone sensors located below the cooktop
surface require that certain cookware conditions are met
before the induction cooking zones can operate.
The cooking zone display windows may display a pan
sensing error message. If a cooking zone was activated and
no pan or cookware is detected, the affected induction
cooking zone display window will flash with the last power
level request setting (See Fig. 1).
Important note:
It is recommended that you lower the requested power
level setting before correcting the pan sensing message.
The conditions that may generate an error message are
also illustrated in the incorrect column in Fig. 2. If the
problem or problems are not corrected the affected
cooking zone will automatically deactivate after 3 minutes.
Fig. 1
Correct conditions Incorrect conditions
• Cookware centered
correctly on cooking zone.
• Flat pan bottom and
straight sides.
• Pan size meets or exceeds
the recommended
minimum size for cooking
zone.
• Pan rests completely
and is level on the
cooktop surface.
• Pan is properly balanced.
• Pan does not meet the
minimum size required
(too small) for cooking
zone.
• Heavy handle tilts pan.
• Cookware not centered
on cooking zone.
• Curved or warped pan
bottoms or sides.
• Cookware base material
has good magnetic
characteristics.
• Cookware base material
is non-magnetic.
Fig. 2
• Pan bottom rests on
cooktop edge.
Pan sensing checklist
