9
Installation (Continued)
5. Install the toe grille by tting into place.
Raise
Lower
Anti-tip
Leg
Door
Door
NOTE
View shown is looking up at the bottom
of the refrigerator door.
To adjust the door stop:
Door stop is adjustable between 85 to 145
degrees.
1. Open door to provide access to screw.
2. Loosen screw.
3. Adjust door to desired location.
4. Rotate door stop until it makes contact
with the lower hinge.
5. Retighten screw.
Rotate
Door to Desired
Location
Adjusting Door
Adjustable Door Stop
Door
Stop
Screw
Lower
Hinge
Min
Open
Max
Open
6. Ensure door stops in desired location
before resuming normal use.
To level the doors using the adjustable
lower hinge (select models):
1. Remove all food items from door bins
on door being adjusted.
2. Open doors to 90 degrees.
Rotate
Door
Stop
Re-tighten
Screw
Retighten Screw
To Next Page
