PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from those on
your particular grill model. However, the method of assembly remains the same.
14 · 466424712
To order replacement parts after using grill,
call 1-800-241-7548.
Key Qty Description Part #
40 1 SIDEBURNER 302140010
41 1 SIDEBURNER GRATE 302080010
42 1 GREASE TRAY SH101002711
43 1 HEAT SHIELD, F/ TANK SH101002719
44 1 GREASE PAN 202140010
45 4 HEAT DIFFUSER 202150009
46 2 COOKING GRATE 302110037
47 1 WARMING RACK 302070017
48 1 WING SCREW TANK SH101002721
… 1 HARDWARE PACK 505000039
… 1 ASSEMBLY MANUAL, ENGLISH 307010129
… 1 ASSEMBLY MANUAL, FRENCH 307010130
NOT Pictured
Key Qty Description Part #
1 1 LEFT FRONT LEG SH101002725
2 1 LEFT REAR LEG SH101002726
3 2 LEG EXTENDER 302470076
4 1 RIGHT FRONT LEG SH101002723
5 1 RIGHT REAR LEG SH101002724
6 1 MATCH HOLDER SH101002728
7 1 BOTTOM SHELF SH101002720
8 2 WHEEL 302450005
9 1 AXLE ROD 302460003
10 2 WHEEL SPACER 302470077
11 2 SIDE BRACE, F/ CART SH101002722
12 2 FRONT PANEL 204060004
13 1 TANK EXCLUSION 302470136
14 1 GRILL LID SH101002701
15 1 BEZEL, F/ TEMPERATURE GAUGE 201150002
16 1 TEMPERATURE GAUGE SH302020010
17 1 HANDLE, F/ LID SH101002703
18 2 HANDLE END, F/ LID HANDLE 201090001
19 4 LID BUMPER 302060001
20 1 TOP LID HARDWARE SH101002704
21 1 FIREBOX, GRILL BOTTOM SH101002705
22 4 MAIN BURNER 302120027
23 1 ELECTRODE, MAIN BURNER SH101002706
24 1 BURNER CARRY OVER TUBE SH101002707
25 1 BRACKET, F/ CONTROL PANEL, LEFT SH101002708
26 1
BRACKET, F/ CONTROL PANEL,
RIGHT
SH101002709
27 1 CONTROL PANEL, MAIN SH101002732
28 1 ELECTRONIC IGNITION MODULE 302260011
29 1 BUTTON, F/ IGNITION MODULE 302260011-1
30 1
HOSE VALVE REGULATOR
ASSEMBLY
SH101002727
31 5 BEZEL F/ CONTROL KNOB 302240001
32 5 CONTROL KNOB 302230015-3
33 1 LEFT FASCIA SH101002731
34 1 LEFT SIDE SHELF SH101002717
35 1 RIGHT FASCIA SH101002730
36 1 RIGHT SIDE SHELF SH101002712
37 1 DRIP PAN, F/ SB SH101002729
38 1 SIDE BURNER LID SH101002715
39 1 ELECTRODE, F/ SB SH101002714
