Side Braces
□ Turn cart upright.
□ Attach side braces to legs using four 1/4-20x1/2" machine screws on each side. Make sure that flat
side of brace faces to cart interior. Orient side braces so that the threaded inserts are at the top.
Machine Screws
Qty. 8
1/4-20x1/2"
4
Front Panels
Side Brace
Machine Screws
Qty. 11
#8-32x3/8"
Keps Nut
Qty. 1
#8-32
Side Brace
Machine Screw
#8-32x3/8"
Front Panels
Machine Screw
#8-32x3/8"
Bottom Shelf
□ Fit one front panel between front legs and attach with two #8-32x3/8"machine screws each side.
Then attach the front panel to bottom shelf with two #8-32x3/8"machine screws.
□ Fit the other front panel between front legs and attach with two #8-32x3/8"machine screws each
side. Then use one #8-32x3/8"machine screw and keps nut to secure two front panels in the middle
hole as shown.
