12
Grease Tray and Grease Pan
□ Slide grease tray, oriented as shown, onto rails beneath firebox past rail stops. Slide grease pan
onto rails beneath grease tray past rail stops.
413
Heat Diffusers
□ Place heat diffusers over burners as shown. Diffuser ends insert into channels on front and back of
firebox.
Failure to install grease cup clip and cup
will cause hot grease to drip from bottom
of grill with risk of fire or property damage.
CAUTION
Grease Tray
Grease Pan
Heat Diffuser
Grease Tray
466424712 · 23
