Kenmore D02 M90348 - Page 18

3
• Hang tank exclusion wire onto lower back panel, attach other end to bottom shelf with #8x3/8” sheet metal screw.
#8x3/8"
Sheet Metal Screws
Qty. 1
Lower Back Panel
4
• Place front door brace as shown. Attach to left and right leg assemblies with 1/4-20x2-3/8" machine screws and
1/4-20 flange nuts.
Front Door Brace
1/4-20
Flange Nut
Qty: 4
1/4-20x2-3/8"
Machine Screw
Qty: 4
18 • 466226113
