17
• LP tank is sold separately. Use only with an OPD (over-fill protection device) equipped LP tank. Fill and leak-check
before attaching to grill and regulator. See Use and Care section to correctly Leak Test and perform the Burner Flame
Check.
• Place LP tank into hole in bottom shelf with tank collar opening facing to the front as shown. Finger tighten tank
thumbscrew to hold LP tank securely in place.
CAUTION
Failure to install tank correctly may
allow gas hose to be damaged in
operation, resulting in the risk of
fire.
Always keep LP cylinders in
upright position during use,
transport, and storage.
Regulator
Tank Retainer Screw
16
• Attach the heat shield to grease tray with #8x3/8” sheet metal screws (A).
• Place grease pan into grease tray, then place the tray into the cart (B).
A
B
Heat Shield
Grease Tray
CAUTION
Failure to install grease tray and
grease pan will cause hot grease to
drip from bottom of grill with risk of
fire or property damage.
#8x3/8"
Sheet Metal Screws
Qty. 4
Grease Pan
Grease Tray
LP Tank
LP Cylinder
(not included)
Cylinder screw at rear of cart
466226113 • 27
