Kenmore PG-40407S0LF-1 - Page 27

Left Side Shelf
□ Attach Side Shelf Handle to Fascia Left Side Shelf with (2) Pre-installed M6x15 Screws and (2) Pre-installed M6
Compression Washers as shown.(A)
□ Attach Left Side Shelf to the cart with (2) M4x10 Screws as shown. (B)
Note: (Make sure holes on side shelf align with the holes on cart.).
□ Attach left side shelf to firebox from inside to outside of firebox with (2) M6x15 Screws and (2) M6 Compression Washers
as shown.(C)
27
10
M6X15 Screw Qty: 2 pcs
M6 Compression Washer Qty: 2 pcs
M4X10 Screw Qty: 2 pcs
A
B
C
