Introduction
Product Specifications
Preparing for the New Installation
Thank You for purchasing a Sears water heater.
Properly installed and maintained, it should give you years of
trouble free service. If you should decide that you want the new
water heater professionally installed, contact the local Sears
Service Center or any Sears store. They will arrange for prompt,
quality installation by Sears authorized contractors.
Abbreviations Found In This Instruction Manual
U.L. - Underwriters Laboratories Inc.
NEC - National Electrical Code
ANSI - American National Standards Institute
*Wiring size based on standard 60°C copper wire. If distance from fuse box to water heater is more than 90 feet, refer to your local electri-
cal code.
4
TANK
MODEL CAPACITY DIMENSIONS IN INCHES
NUMBER IN GALLONS DIAMETER HEIGHT
40 25″ 32
1
⁄
4
″
30 19″ 47″
40 19″ 60″
50 21
1
⁄
2
″ 61″
66 23″ 61″
80 25″ 61
1
⁄
2
″
ELEMENT MAXIMUM FUSE
RECOVERY RATE WATTAGE MINIMUM OR CIRCUIT
GALS. PER HOUR AT 240 VOLTS WIRE SIZE* BREAKER
@90°F. RISE UPPER LOWER (GAUGE) SIZE (AMPS)
17.3 3800 3800 12 20
25.0 3800 5500 10 30
17.3 3800 3800 12 20
25.0 3800 5500 10 30
17.3 3800 3800 12 20
25.0 3800 5500 10 30
17.3 3800 3800 12 20
25.0 3800 5500 10 30
17.3 3800 3800 12 20
25.0 3800 5500 10 30
17.3 3800 3800 12 20
25.0 3800 5500 10 30
153.329260
153.329261
153.329360
153.329361
153.329460
153.329461
153.329560
153.329561
153.329660
153.329661
153.329860
153.329861
• Read the “Safety Precautions” section, page 2 of this manual
first and then the entire manual carefully. If you don’t follow
the safety rules, the water heater will not operate properly. It
could cause DEATH, SERIOUS BODILY INJURY
AND/OR PROPERTY DAMAGE.
This manual contains instructions for the installation, opera-
tion, and maintenance of this electric water heater. It also
contains warnings throughout the manual that you must read
and be aware of. All warnings and all instructions are essential
to the proper operation of the water heater and your safety.
Since we cannot put everything on the first few pages, READ
THIS ENTIRE MANUAL BEFORE ATTEMPTING TO
INSTALL OR OPERATE THE WATER HEATER.
• The installation must conform with the instructions in this
manual; electric company rules; and Local Codes, or in the
absence of Local Codes, with the current edition of the NEC,
National Electrical Code, NFPA 70. This publication is avail-
able from your local government or public library or electric
company or by writing Underwriters Laboratories Inc., 333
Pfingsten Road, Northbrook, IL 60062.
• If after reading this manual you have any questions or do not
understand any portion of the instructions, call Sears Service
Center.
• Carefully plan the place where you are going to put the water
heater. Correct electrical wiring and connections are very
important in preventing death from possible electrical shock
and fires.
Examine the location to ensure the water heater complies
with the “Facts to Consider About the Location” section.
• For California installation this water heater must be braced,
anchored, or strapped to avoid falling or moving during an
earthquake. See instructions for correct installation proce-
dures. Instructions may be obtained from the California office
of the State Architect, 400 P Street, Sacramento, CA 95814.
• Massachusetts Code requires this water heater to be installed
in accordance with Massachusetts 248-CMR 2.00: State
Plumbing Code and 248-CMR 5.00.
To Next Page
