WARNING
The motorized nozzle contains an
EASYCUT™ blade. It has an extremely
sharp edge inside. Do not touch the
blade when performing maintenance.
- 14 -
The motorized nozzle may accumulate
debris such as strings, hair and fibers. This
type of debris can wrap around the brush
and diminish its ability to clean effectively.
The EASYCUT™ blade in the motorized
nozzle will cut debris accumulation away
from the brush roll.
Recommended: After every use, clean the
brush roll with the EASYCUT™ system by
stepping on the button for 1-2 seconds
as illustrated while the vacuum cleaner is
operating. Repeat above step more than 5
times for better performance.
NOTE:
It is recommended to use the
EASYCUT™ system while the battery is
fully charged.
Brush Roll Manual Cleaning
1. Make sure the vacuum cleaner is turned
OFF. Remove the floor head from the
handle assembly and turn it over to
access the brush roll.
2. Unlock the brush roll tab using a flat
head screwdriver or similar tool.
3. Lift the brush roll out of the housing.
Clean off debris and anything wrapped
around the brush.
4. Place the brush roll into the housing
by aligning the end to the brush drive
side first, then inserting the other end
correctly into place. When installed
correctly, the brush roll will spin freely.
Lock the brush roll into place by securing
the locking tab back into position.
CLEANING THE MOTORIZED NOZZLE & BLOCKAGES
EASYCUT™ Button
