2. Flex the connection hose to ensure you
can see straight through the other end. If
you can see any blockages in this area,
carefully remove them.
3. Reattach the motorized nozzle onto the
vacuum body.
NOTE:
Do not use scissors or other
sharp objects to remove a blockage from
the hose as these may damage the hose.
Brush Roll Reset
If the brush roll is blocked or overloaded,
the brush roll will stop turning and the LED
lights on the nozzle will flash ten times and
then turn off. The nozzle motor will turn off
while the unit motor stays on. Switch the
unit off and remove the obstruction to reset
the brush roll.
Hose Blockage Removal
1. To clean out the hose, press the hose
release tabs, as illustrated, and pull the
motorized nozzle away from the main
vacuum body.
1
1
2
2
- 15 -
CLEANING THE MOTORIZED NOZZLE & BLOCKAGES
WARNING
This product contains the EASYCUT™
blade. Do not touch the blade
when performing motorized brush
maintenance.
EASYCUT™ BLADE
