PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
DDX7019/7029/7029Y/7039
DNX7100/7200
57
K
: DDX7019
K1
: DNX7100 (North America)
E1
: DDX7029
E2
: DDX7029Y
E3
: DNX7200 (Europe)
X1
: DDX7039 (Australia)
R1
: DDX7039 (Latin America)
M1
: DDX7039 (Other Areas)
259 2G G02-1544-04 FLAT SPRING
260 2G G02-1545-04 FLAT SPRING
264 2E G16-1628-04 SHEET
267 2F G16-1638-04 SHEET
-
✽
H54-3969-03 ITEM CARTON CASE K
-
✽
H54-3970-03 ITEM CARTON CASE E1
-
✽
H54-3971-03 ITEM CARTON CASE E2
-
✽
H54-3972-03 ITEM CARTON CASE M1X1
-
✽
H54-3974-03 ITEM CARTON CASE K1
-
✽
H54-3975-03 ITEM CARTON CASE E3
-
✽
H54-4065-03 ITEM CARTON CASE R1
268 1E H30-0595-04
ADHESIVE DOUBLE-COATED TAPE KR1M1
268 1E H30-0595-04 ADHESIVE DOUBLE-COATED TAPE X1K1
269 1E J21-9867-04 MOUNTING HARDWARE K1E3
272 1H J22-0444-13 MOUNTING HARDWARE ASSY
275 1E J22-0498-13 MOUNTING HARDWARE ASSY
277 2E J22-0503-02 MOUNTING HARDWARE ASSY
282 3G J31-1075-14 COLLAR (ARM COLLAR)
283 2G J31-1077-04 COLLAR (PANEL COLLAR)
286 2H J90-1124-13 GUIDE ASSY
287 2H J90-1126-13 GUIDE ASSY
288 2H J90-1128-03 RAIL
289 3G
✽
J90-1129-23 RAIL
290 3G
✽
J90-1130-23 RAIL
291 3G J90-1131-03 GUIDE
293 3C J90-1135-11 RAIL
294 3C J90-1136-11 RAIL
FPC1 3D
✽
J86-0034-05 FPC (LEAD FREE)
296 3E K24-4555-03 PUSH KNOB (SRC)
E1E2R1
296 3E K24-4555-03 PUSH KNOB (SRC) KM1X1
296 3E
✽
K24-4684-13 PUSH KNOB (SRC) K1E3
297 3E K24-4556-03 PUSH KNOB (ATT)
298 3E
✽
K24-4685-04 PUSH KNOB (RESET)
299 3E K24-4560-03 PUSH KNOB (EJECT)
300 3E K25-1822-03 PUSH KNOB (FNC/V.SEL)
301 3E K25-1823-03 PUSH KNOB (VOL)
303 1E N99-1776-05 SCREW SET
KR1M1
303 1E N99-1776-05 SCREW SET X1K1
A 3C N86-2605-48
BINDING HEAD TAPTITE SCREW
AA 2E N35-2003-48 BINDING HEAD MACHINE SCREW
C 3E N09-6232-05 MACHINE SCREW (M2X3)
E 1D N35-2604-43
BINDING HEAD MACHINE SCREW
F 3C N09-6360-05 STEPPED SCREW (PANEL SCREW)
G 1H N09-6361-05 MACHINE SCREW (M2X2.5)
H 1H N09-6363-05 MACHINE SCREW (M1.7X3.7)
J 3G N09-6375-05 MACHINE SCREW (M2X2.5)
K 2G N09-6376-05 MACHINE SCREW (M2X3.5)
L 3G N09-6377-05 MACHINE SCREW (M2X2.5)
M 2G N09-6378-05 TAPTITE SCREW (STITE 2X2)
N 2H N09-6379-05 MACHINE SCREW (M2.6X4)
R 2C N09-6400-05 MACHINE SCREW (M2.6X27)
S 3E N09-6401-05 TAPTITE SCREW
T 3C N09-6402-05 MACHINE SCREW (M2.6X5)
U 1D N09-6403-05 MACHINE SCREW
W 3C N09-6425-15 MACHINE SCREW (M3X5)
X 2E N19-2317-04 FLAT WASHER (1.2X3.2X0.25)
Y 1H N19-2321-04 FLAT WASHER (1.6X4X0.25)
304 1H R31-0248-05 VARIABLE RESISTOR
305 3F S79-0854-05 SWITCH ASSY
306 1E T90-0552-05 ANTENNA ADAPTOR
E1E2E3
PM1 1H T42-1322-14 MOTOR ASSY
307 1F
✽
W02-5229-05 ELECTRIC CIRCUIT MODU (GPS-ANT) K1E3
308 3D
✽
W02-5236-05 ELECTRIC CIRCUIT MODULE (NAVI-K K1
308 3D
✽
W02-5237-05 ELECTRIC CIRCUIT MODULE (NAVI-E E3
VME1 1D
✽
X92-5920-00 DVD MECHANISM ASSY (DVS-8530V)
C1 C90-5670-05 ELECTRO 2200UF 16WV
C2,3 CK73GB1H104K CHIP C 0.10UF K
C4 CK73FB1E474K CHIP C 0.47UF K
C5 CE32BF1C221M CHIP EL 220UF 16WV
C6 CE32BF0J101M CHIP EL 100UF 6.3WV
C7 CK73FB0J106K CHIP C 10UF K
C8 CK73GB1H104K CHIP C 0.10UF K
C9 CK73FB1A225K CHIP C 2.2UF K
C10 CK73EB1A106K CHIP C 10UF K
C11 CK73GB1H103K CHIP C 0.010UF K
C12 CK73EB1A106K CHIP C 10UF K
C13 CK73GB1H103K CHIP C 0.010UF K
C14 CE32BJ1C100M CHIP EL 10UF 16WV
C16 CK73EB1C106K CHIP C 10UF K
C17 CE32BF1E101M CHIP EL 100UF 25WV
C19 CK73GB1H103K CHIP C 0.010UF K
C20 CK73GB1H104K CHIP C 0.10UF K
C21,22 CK73FB0J106K CHIP C 10UF K
C24 CK73EB1C106K CHIP C 10UF K
C26 CK73GB1A105K CHIP C 1.0UF K
C27,28 CK73GB1H104K CHIP C 0.10UF K
C29 CK73FB0J106K CHIP C 10UF K
C34 CK73FB0J106K CHIP C 10UF K
C101 CK73GB1H473K CHIP C 0.047UF K
C102 CK73GB1H102K CHIP C 1000PF K
C104 CC73GCH1H221J CHIP C 220PF J
C105 CK73GB1H102K CHIP C 1000PF K
C106 CK73GB1H103K CHIP C 0.010UF K
C107,108 CC73GCH1H101J CHIP C 100PF J
C109 CK73GB1H223K CHIP C 0.022UF K
C110 CC73GCH1H470J CHIP C 47PF J
C111 CK73GB1H103K CHIP C 0.010UF K
C112 CK73GB1H102K CHIP C 1000PF K
C114 CC73GCH1H221J CHIP C 220PF J
C115 CK73GB1H473K CHIP C 0.047UF K
C116 CK73GB1H104K CHIP C 0.10UF K
C117 CK73FB0J106K CHIP C 10UF K
C118 CK73GB1H104K CHIP C 0.10UF K
C119 CK73EB1E225K CHIP C 2.2UF K
C120,121 CK73GB1H104K CHIP C 0.10UF K
VIDEO CONTROL UNIT (X14-985x-xx)
DDX7019/7029/7029Y/7039, DNX7100/7200
