Kenwood DDX7029 Service Manual

SPECIFICATIONS
DANGER:
Please do not look at the laser beam directly during
re pair or operation check.
DDX7019/7029/7029Y/7039
DNX7100/7200
Monitor section
Picture size ................. 6.95 inches (diagonal) wide, 156.2 x 82.4mm
Display system ........................................ Transparent TN LCD panel
Drive system ...............................................TFT active matrix system
Number of pixels ................................ 336,960 (480H x 234V x RGB)
Effective pixels ........................................................................99.99%
Pixel arrangement......................................RGB striped arrangement
Back lighting .....................................Cold Cathode Fluorescent Tube
DVD section
D/A Converter ............................................................................. 24bit
Decoder ...................Linear PCM/ Dolby Digital/ dts/MP3/ WMA/AAC
Wow & Flutter ...............................................Below Measurable Limit
Frequency Response
Sampling frequency; 96kHz ...................................... 20~44,000Hz
Sampling frequency; 48kHz ...................................... 20~22,000Hz
Sampling frequency; 44.1kHz ................................... 20~20,000Hz
Total Harmonic Distortion ............................................. 0.01% (1kHz)
S/N Ratio ........................................................98dB (DVD-Video 96k)
Dynamic Range ..............................................98dB (DVD-Video 96k)
DISC Format .................................... DVD-Video/ VIDEO-CD/ CD-DA
Sampling frequency ...................................... 44.1kHz/ 48kHz/ 96kHz
Quantifying bit number .................................................. 16/ 20/ 24 bit
USB IF section
USB Standard ................................................................ USB 1.1/ 2.0
File System ........................................................................FAT 16/ 32
Maximum Power Supply Current ............................................ 500mA
D/A Converter .............................................................................24Bit
Decoder ...................................................................MP3/ WMA/ AAC
FM tuner section
Frequency Range
K,K1,R1 ..................................................87.9~107.9MHz (200kHz)
M1,X1 ............87.5~108.0MHz (50kHz), 87.9~107.9MHz (200kHz)
E1,E2,E3 ..................................................87.5~108.0MHz (50kHz)
Usable Sensitivity
K,K1,R1 (S/N : 30dB) ........................................9.3dBf (0.8µv/75
Ω
)
M1,X1 (S/N : 26dB) ..........................................9.3dBf (0.8µV/75
Ω
)
E1,E2,E3 (S/N : 26dB) ................................................... 0.7µv/75
Ω
Quieting Sensitivity
K,K1,R1 (S/N : 50dB) .....................................15.2dBf (1.6µV/75
Ω
)
M1,X1,E1,E2,E3 (S/N : 46dB) ........................ 15.2dBf (1.6µV/75
Ω
)
Frequency Response (± 3.0dB) ..................................... 30Hz~15kHz
Total Harmonic Distortion
K1 .............................................................................. 0.01% (1kHz)
S/N
K,R1,M1,X1 ..............................................................70dB (MONO)
K1 .............................................................................75dB (MONO)
E1,E2,E3 ..................................................................65dB (MONO)
Selectivity (±400kHz) ...............................................................
≥
80dB
Stereo Separation
K,K1,R1,M1,X1 ...........................................................40dB (1kHz)
E1,E2,E3 .....................................................................35dB (1kHz)
AM tuner section : K,K1,R1,X1 type
Frequency Range
K,K1,R1 .......................................................530~1700kHz (10kHz)
X1 ............................ 531~1611kHz (9kHz), 530~1700kHz (10kHz)
Usable Sensitivity .................................................................... 28dBµ
LW Tuner section : M1,E1,E2,E3 type
Frequency Range ...............................................153~281kHz (9kHz)
Usable Sensitivity
M1 ........................................................................................ 28dBµ
E1,E2,E3 ................................................................................ 45µV
MW Tuner section : M1,E1,E2,E3 type
Frequency Range
M1 ........................... 531~1611kHz (9kHz), 530~1700kHz (10kHz)
E1,E2,E3 .......................................................531~1611kHz (9kHz)
Usable Sensitivity .........................................................28dBµ (25µV)
Video section
Color system of external video input
K,K1,R1 ................................................................................. NTSC
M1,X1,E1,E2,E3 ...........................................................NTSC/ PAL
External video input level (RCA jacks) ...............................1Vp-p/75
Ω
External audio max input level (RCA jacks) .......................... 2V/25k
Ω
Analog RGB input
K,R1,M1,X1,E1,E2 ......................................................0.7Vp-p/75
Ω
Video Output level (RCA jacks) .........................................1Vp-p/75
Ω
Audio Output level (RCA jacks) .........................................1.2V/10k
Ω
Audio section
Maximum Power (Front & Rear) ............................................50W x 4
Full Bandwidth Power (Front & Rear)
K,K1,R1 (4
Ω
, 14.4V, 1% THD) .......................................... 22W × 4
M1,X1 (at less than 1% THD) ............................................22W x 4
E1,E2,E3 (PWR DIN45324, +B=14.4V) .............................30W x 4
Preout level ........................................................................... 2V/10k
Ω
Preout impedance ..................................................................
≤
600
Ω
Speaker impedance ................................................................... 4~8
Ω
Tone action
Bass ............................................................................. 100Hz±8dB
Middle ............................................................................ 1kHz±8dB
Treble ........................................................................... 10kHz±8dB
External SW : K1,M1,X1,E3 type
Maximum Power Supply Current ............................................ 500mA
General
Operating voltage ......................................14.4V (11~16V allowable)
Current Consumption .................................................................. 15A
Installation Size (W × H × D)
...................... 182 × 112 × 163 mm, 7-3/16 × 4-7/16 × 6-7/16 inch
Operational Temperature Range .................................. -10°C~+60°C
Storage Temperature Range ........................................ -20°C~+85°C
Weight
K,R1,M1,X1,E1,E2 .................................................. 2.65kg (5.8lbs)
K1,E3 ...................................................................... 2.85kg (6.3lbs)
KENWOOD follows a policy of continuous advancements in
development. For this reason specifications may be changed
without notice.
Although the effective pixels for the liquid crystal panel is given
as 99.99% or more, 0.01% of pixels may not light or may light
incorrectly.
US and foreign patents licensed from Dolby Laboratories.
