Kenwood DDX7029 Service Manual

PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
DDX7019/7029/7029Y/7039
DNX7100/7200
75
K
: DDX7019
K1
: DNX7100 (North America)
E1
: DDX7029
E2
: DDX7029Y
E3
: DNX7200 (Europe)
X1
: DDX7039 (Australia)
R1
: DDX7039 (Latin America)
M1
: DDX7039 (Other Areas)
R481,482 RK73HB1J000J CHIP R 0.0 J 1/16W
R485-487 RK73HB1J000J CHIP R 0.0 J 1/16W
R494 RK73HB1J000J CHIP R 0.0 J 1/16W
R496 RK73HB1J000J CHIP R 0.0 J 1/16W
R498 RK73HB1J000J CHIP R 0.0 J 1/16W
R500 RK73HB1J000J CHIP R 0.0 J 1/16W
R502,503 RK73HB1J000J CHIP R 0.0 J 1/16W
R505-507 RK73HB1J000J CHIP R 0.0 J 1/16W
R509 RK73HB1J000J CHIP R 0.0 J 1/16W
R522 RK73HB1J680J CHIP R 68 J 1/16W
R523 RK73HB1J000J CHIP R 0.0 J 1/16W
R524 RK73HB1J330J CHIP R 33 J 1/16W
R527 RK73HB1J000J CHIP R 0.0 J 1/16W
R701 RK73HB1J000J CHIP R 0.0 J 1/16W
D102,103 AVRL1613R3FTA VARISTOR
D104,105 IMSA-6802-E SURGE ABSORBER
D300 DA204U DIODE
IC100 MIC2005-05YM6 MOS-IC
IC104 TC7S86FU-F MOS-IC
IC105 SI-3018KM ANALOGUE IC
IC106 - MICROPROCESSOR IC
IC108 TC7SH04FU-F MOS-IC
IC200 TC7WHU04FU-F MOS-IC
IC201 TC74LCX245FT MOS-IC
IC202,203
✽
K4S561632HUI7 DRAM IC
IC205 TC74LCX245FT MOS-IC
IC207
✽
341S1962 MICROPROCESSOR IC
IC211
✽
DW128F70NF9W7 ROM IC
IC301
✽
WM8728SEDSR ANALOGUE IC
IC302
✽
BH7240AKV MOS-IC
IC305 NJM2100V-ZB ANALOGUE IC
IC309
✽
LC74735NW8A20 MOS-IC
IC316 TC7WHU04FU-F MOS-IC
IC322
✽
L4032VN8IPINO MOS-IC (48PIN 32V)
IC332 NJM2864F05-ZB ANALOGUE IC
IC336,337 TC7WH14FU-F MOS-IC
Q302-304 2SA1576A TRANSISTOR
D1 B30-1566-05 LED (1608,RED)
D2-7 B30-1767-05 LED
D9 B30-1767-05 LED
C9,10 CK73GB1A105K CHIP C 1.0UF K
FPC2 3E
✽
J86-0023-15 FPC (LEAD FREE)
S1-8 S70-0919-05 TACT SWITCH
D8 AVRM1608120M6A VARISTOR
D10-17 AVRM1608120M6A VARISTOR
IC1 GP1US301XP ANALOGUE IC
1 1A
✽
A10-5331-41 CHASSIS
2 2B A10-5332-41 CHASSIS
3 1A A10-5333-31 CHASSIS
4 3A A10-5334-22 CHASSIS
7 1B
✽
D10-4918-12 ARM
8 1B
✽
D10-4919-12 ARM
9 1B
✽
D10-4920-02 LEVER
10 1B
✽
D10-4921-02 LEVER
12 2B
✽
D10-4922-12 SLIDER
13 2A
✽
D10-4923-12 ARM
14 2B
✽
D10-4924-13 ARM
15 2B
✽
D10-4925-12 ARM
25 2B
✽
D10-4938-04 SLIDER ASSY
27 2A
✽
D10-4945-04 LEVER
28 2B
✽
D12-0639-02 CAM
31 2B
✽
D13-2402-04 GEAR
32 2B
✽
D13-2403-04 GEAR
33 2B
✽
D13-2404-04 GEAR
34 2B
✽
D13-2405-04 GEAR
35 2B
✽
D13-2406-04 GEAR
36 2B
✽
D13-2407-04 GEAR
40 2A D13-2413-04 GEAR
41 2A D13-2415-04 GEAR
42 2A D13-2416-04 GEAR
43 1B
✽
D14-1013-14 ROLLER
53 1B
✽
D21-2487-04 SHAFT
54 2A
✽
D39-0269-05 DAMPER
55 2A
✽
D39-0270-05 DAMPER
60 3A
✽
F09-2825-23 SHEET
65 2B
✽
G01-3298-04 EXTENSION SPRING
66 1B
✽
G01-3299-04 EXTENSION SPRING
67 2A
✽
G01-3300-14 TORSION COIL SPRING
68 1B
✽
G01-4601-04 EXTENSION SPRING
69 1B
✽
G01-4602-04 EXTENSION SPRING
70 1B
✽
G01-4604-04 TORSION COIL SPRING
74 2B
✽
G01-4609-14 TORSION COIL SPRING
75 1B
✽
G02-1550-03 FLAT SPRING
79 2A J22-0475-11 MOUNTING HARDWARE
80 3B
✽
J22-0476-01 MOUNTING HARDWARE
A 1A
✽
N09-6382-05 MACHINE SCREW (M1.7X2.0)
B 3B
✽
N09-6408-15 TAPTITE SCREW (1.7X4 P-TITE)
C 1B
✽
N09-6426-15 MACHINE SCREW (LOAD ARM SCREW
D 3A N09-6104-05 MACHINE SCREW (2X10 S-TITE)
93 2A
✽
T99-0471-05 MAGNET
96 1B X94-2080-00 ROLLER ASSY
98 2A X94-2060-00
TRAVERSE ASSY (PICKUP,SPINDLE)
VM1 2A X94-2070-00 MOTOR ASSY (LOADING)
DAUGHTER UNIT (X89-2980-10)
DVD MECHANISM ASSY (X92-5920-00) (DVS-8530V)
DIGITAL I/O UNIT (X88-2020-12)
●
IC106 in the DIGITAL I/O UNIT (X88-2020-
12) is not a replaceable component. In case
of defective of this IC, replace the entire unit
(X88-2020-12).
