PARTS LIST
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
K
: DDX7019
K1
: DNX7100 (North America)
E1
: DDX7029
E2
: DDX7029Y
E3
: DNX7200 (Europe)
X1
: DDX7039 (Australia)
R1
: DDX7039 (Latin America)
M1
: DDX7039 (Other Areas)
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
DDX7019/7029/7029Y/7039
DNX7100/7200
56
208 1D
✽
A22-3126-11 SUB PANEL ASSY E1E2R1
208 1D
✽
A22-3126-11 SUB PANEL ASSY KM1X1
208 1D
✽
A22-3128-21 SUB PANEL ASSY K1E3
209 1D A52-0878-02 TOP PLATE
210 1F
✽
A46-1842-12 REAR COVER
PA1 3E
✽
A64-4140-01 PANEL ASSY K
PA1 3E
✽
A64-4141-01 PANEL ASSY E1E2
PA1 3E
✽
A64-4142-01 PANEL ASSY M1
PA1 3E
✽
A64-4143-01 PANEL ASSY R1X1
PA1 3E
✽
A64-4144-11 PANEL ASSY K1
PA1 3E
✽
A64-4145-11 PANEL ASSY E3
PME1 3C
✽
A10-5300-31 CHASSIS ASSY
RC1 1F
✽
A70-2082-15 REMOTE CONTROLLER AS (RC-DV330) E3
RC1 1F
✽
A70-2082-15 REMOTE CONTROLLER AS (RC-DV330) M1X1K1
RC1 1F
✽
A70-2083-15 REMOTE CONTROLLER AS (RC-DV340) E2
RC1 1F
✽
A70-2083-15 REMOTE CONTROLLER AS (RC-DV340) KR1E1
- B46-0612-14 ID CARD E1E2M1
- B46-0612-14 ID CARD X1E3
-
✽
B54-4522-00 INSTALLATION MANUAL (ENG.SPA.) KR1
-
✽
B54-4523-00 INSTALLATION MANUAL (FRE.) K
-
✽
B54-4524-00 INSTALLATION MANUAL (POR.) R1
-
✽
B54-4525-00 INSTALLATION MANUAL (ENG.) E1E2
-
✽
B54-4526-00 INSTALLATION MANU(FRE.GER.DUT) E1
-
✽
B54-4527-00 INSTALLATION MANUAL (ENG.) M1X1
-
✽
B54-4528-00 INSTALLATION MANUAL (T-CHI.KOR. M1
-
✽
B54-4530-00 INSTALLATION MANU (ENG.FRE.SPA) K1
-
✽
B54-4531-00 INSTALLATION MANU (ENG.FRE.GER) E3
-
✽
B59-1880-00 SUB-INSTRUCTION MANUAL
-
✽
B64-3589-00 INSTRUCTION MANUAL (ENG.) KR1
-
✽
B64-3590-00 INSTRUCTION MANUAL (FRE.) K
-
✽
B64-3591-00 INSTRUCTION MANUAL (SPA.) KR1
-
✽
B64-3592-00 INSTRUCTION MANUAL (POR.) R1
-
✽
B64-3593-00 INSTRUCTION MANUAL (ENG.) E1E2
-
✽
B64-3594-00 INSTRUCTION MANUAL (FRE.) E1
-
✽
B64-3595-00 INSTRUCTION MANUAL (GER.) E1
-
✽
B64-3596-00 INSTRUCTION MANUAL (DUT.) E1
-
✽
B64-3597-00 INSTRUCTION MANUAL (ITA.) E1
-
✽
B64-3598-00 INSTRUCTION MANUAL (SPA.) E1
-
✽
B64-3599-00 INSTRUCTION MANUAL (POR.) E1
-
✽
B64-3600-00 INSTRUCTION MANUAL (ENG.) M1X1
-
✽
B64-3601-00 INSTRUCTION MANUAL (T-CHI.) M1
-
✽
B64-3602-00 INSTRUCTION MANUAL (KOR.) M1
-
✽
B64-3604-00 INSTRUCTION MANUAL (NAVI-K) K1
-
✽
B64-3605-00 INSTRUCTION MANUAL (NAVI-E) E3
-
✽
B64-3644-00 INSTRUCTION MANUAL (ENG.) K1
-
✽
B64-3645-00 INSTRUCTION MANUAL (FRE.) K1
-
✽
B64-3646-00 INSTRUCTION MANUAL (SPA.) K1
-
✽
B64-3647-00 INSTRUCTION MANUAL (ENG.) E3
-
✽
B64-3648-00 INSTRUCTION MANUAL (FRE.) E3
-
✽
B64-3649-00 INSTRUCTION MANUAL (GER.) E3
-
✽
B64-3650-00 INSTRUCTION MANUAL (DUT.) E3
-
✽
B64-3651-00 INSTRUCTION MANUAL (ITA.) E3
-
✽
B64-3652-00 INSTRUCTION MANUAL (SPA.) E3
-
✽
B64-3653-00 INSTRUCTION MANUAL (POR.) E3
211 1E B07-3172-12 ESCUTCHEON
KR1M1
211 1E B07-3172-12 ESCUTCHEON X1K1
212 1E B07-3173-11 ESCUTCHEON
213 3G B09-0541-04 CAP
216 3E B43-1518-04 BADGE
LCD1 3F B38-1186-05 LCD
217 1E D10-4674-04 LEVER
218 3G D10-4895-12 SLIDER ASSY
219 2G D10-4897-13 ARM ASSY
220 3G D10-4899-03 LEVER
221 3G D10-4900-03 LEVER
223 1H D13-2394-04 GEAR
224 1H D13-2395-04 GEAR
225 1H D13-2396-04 GEAR
226 3G D13-2397-03 RACK (GEAR)
227 2E D14-1009-04 ROLLER
228 2H D14-1010-04 ROLLER
229 2G D14-1011-14 ROLLER
230 1H D19-0653-23 CLUTCH ASSY
231 2D
✽
E30-6695-15 CORD WITH PLUG E1E2R1
231 2D
✽
E30-6695-15 CORD WITH PLUG KM1X1
232 2C
✽
E30-6685-05 CORD WITH PINPLUG
233 2C
✽
E30-6686-15 CORD WITH PINPLUG
234 2D
✽
E30-6689-05 CORD WITH PLUG
235 2D
✽
E30-6690-05 CORD WITH PLUG
236 3D
✽
E30-6692-05 CORD WITH PLUG K1E3
237 1F
✽
E30-6693-05 CORD WITH PLUG E3
237 1F
✽
E30-6693-05 CORD WITH PLUG M1X1K1
238 2C
✽
E39-0904-15 WIRING HARNESS K1E3
239 3D
✽
E39-0905-05 WIRING HARNESS K1E3
DC1 1F
✽
E30-6677-05 DC CORD KR1M1
DC1 1F
✽
E30-6677-05 DC CORD X1K1
DC2 1F
✽
E30-6678-05 DC CORD E1E2E3
FC1 3C
✽
E39-0909-05 FLAT CABLE
FC2 2D
✽
E39-0910-05 FLAT CABLE
FC3 3D
✽
E39-0911-05 FLAT CABLE
FC4 3D
✽
E39-0912-05 FLAT CABLE E1E2R1
FC4 3D
✽
E39-0912-05 FLAT CABLE KM1X1
FC4 3D
✽
E39-0920-05 FLAT CABLE K1E3
240 2F
✽
F07-1186-02 COVER
242 2D
✽
F09-2881-04 SHEET E1E2R1
242 2D
✽
F09-2881-04 SHEET KM1X1
243 2D F09-2890-04 CAP
249 2F
✽
F20-2364-23 INSULATING SHEET
251 2C F29-0049-05 INSULATING COVER
F1 2C F52-0023-05 FUSE (MINI BLADE TYPE) 10A
F2 1F F52-0004-05 FUSE (MINI BLADE TYPE) 5A
252 2E G01-3284-04 COMPRESSION SPRING
254 2G G01-3288-04 TORSION COIL SPRING
255 2G G01-3289-04 TORSION COIL SPRING
256 3G G01-3290-04 EXTENSION SPRING
257 1H G02-1539-04 FLAT SPRING
Indicates safety critical com po nents.
DDX7019/7029/7029Y/7039, DNX7100/7200
