13
English |
Installation
Continued on the next page...
Ñ Connecting wires to terminals Ñ Connecting wires to terminals
[1]
USB maximum power supply current :
DC 5 V = 1.0 A
[2]
Sold separately
[3]
Optional accessory
ANT
CAM IN VIDEO OUT VIDEO IN
AV IN
L
R
FRONT OUTREAR OUT
M4x6
5V
=
1.0A
MIC
SUB
WOOFER
PRK SW
REVERSE
DASH CAM
REMO
2 4 6 8
1 3 5 7
2 4 6 8
1 3 5 7
ST REMOTE
INPUT 1
ST REMOTE
INPUT 2
ST REMOTE
GND
Connect to the vehicle’s
parking brake detection
switch harness.
For best safety, be sure to
connect the parking sensor.
Light Green (Parking sensor wire)
Accessory 1: Extension cable
Purple/White (Reverse sensor wire)
Accessory 2:
Bluetooth Microphone
Connect a Dashboard Camera
[3]
.
Connect to vehicle’s reverse
lamp harness when using the
optional rear view camera.
Brown (Dashboard camera interface)
Bright Green/Red
Purple/Red
Gray/Red
Fuse (15A)
Subwoofer Preout
Cap
Cap
FM/AM antenna input
FM/AM
antenna
Connector A
Connector B
USB device
[2]
USB terminal
[1]
(0.8 m)
Accessory 3
Accessory 4
FRONT OUTREAR OUT
VIDEO OUT VIDEO INCAM IN
AV IN
Rear Audio Preout
(Left; White, Right; Red)
AV-IN audio input
(Left; White, Right; Red)
Front Audio Preout
(Left; White, Right; Red)
Visual Output (Yellow)
Rear view camera input (Yellow)
AV-IN visual input
(Yellow)
Connect to vehicle’s steering remote
harness.
Contact your KENWOOD dealer for details.
_B5K-0673-12_DMX1025BT_M_QSG.indb 13 2019/06/17 9:36
