Kenwood DMX8019DABS User Manual

Other External Components
58
TV tuner
You can connect the TV tuner (commercially
available) with this unit and watch TV.
Preparation
• When you use TV control function, connect the
TV tuner (commercially available) and set 3rd
Party TV Tuner Control in AV Setup (P.63) to
ON.
• The TV tuner can be controlled with its supplied
remote control through the remote sensor on the
front panel of this unit.
1
Select [TV] as the source. (P.13)
2
Touch Key display area.
3
Touch [TV Ctrl].
■ Displays the menu/Enters selected item
Touch [MENU/OK].
■ Moves the cursor
Touch [R], [S], [C], [D].
■ Exits menu control
Touch [
].

Kenwood DMX8019DABS Specifications

General

Display type	TFT
Built-in display	Yes
Display diagonal	6.95 \
Display resolution	800 x 480 pixels
DIN size	2 DIN
Output power	200 W
Product color	Black
Frequency range	20 - 88000 Hz
Disc types supported	No
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	98.5 dB
USB version	2.0
Bluetooth range	10 m
Bluetooth version	5.0
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP, SPP
Line outputs (RCA)	1
USB ports quantity	2
USB direct playback	-
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Video formats supported	H.264, MKV, MPEG1, MPEG2, MPEG4, WMV
AM band range	531 - 1701 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, DAB, DAB+, FM
Operating temperature (T-T)	-10 - 60 °C
Cables included	DC, USB

Weight and Dimensions

Depth	153 mm
Width	182 mm
Height	112 mm
Weight	1700 g
