1060CD/1070CD/DP-R6090/R7090/D-R350
2
CONTENTS / ACCESSORIES / CAUTION
CONTENTS / ACCESSORIES / CAUTION ................ 2
EXTERNAL VIEW........................................................3
ADJUSTMENT............................................................ 4
PC BOARD ................................................................. 5
SCHEMATIC DIAGRAM ............................................. 9
EXPLODED VIEW .................................................... 18
PARTS LIST.............................................................. 21
SPECIFICATIONS .....................................................27
Accessories
Contents
Note related to transportation and movement
Before transporting or moving this unit, carry out the following
operations.
1. Turn the power ON but do not load a disc.
2. Wait a few seconds and verify that the display shown appears.
Wait further a few seconds.
3. Turn the power OFF.
Caution
1 2 3 4 5
1 2 3 4 5
6 7 8 9 10
11 12 13 14 15
16 17 18 19 20
no d SC
I
Audio cord (1)
(E30-0505-05)
System control cord (1)
(E30-2733-05)
AC plug adapter (1)
(E03-0115-05)
DP-R6090/R7090/D-R300 : M type only
Remote control unit (1)
(A70-1134-05) : RC-P0601
1060CD/1070CD/DP-R6090/R7090
Batteries (R6/AA) (2)
DP-R4090 only
Battery cover: (A09-0356-08)
1060CD/1070CD(k) COVER( 98.4.24 0:29 PM y[W 3
