16
DPX-MP3110/MP3110S
DPX-MP5110U/MP5110US
Procedure Item Procedure Description
For item
forwarding
procedure,
press [AUD]
key and [FM]
key briefl y
Fader
[VOL] knob and
[
] / [ ] key and
[FM] / [AM] key
Adjust to 3 steps of R15
↔
0
↔
F15. (Default value: 0)
Balance Adjust to 3 steps of L15
↔
0
↔
R15. (Default value: 0)
Bass Level Adjust to 3 steps of -8
↔
0
↔
+8. (Default value: 0)
Middle Level Adjust to 3 steps of -8
↔
0
↔
+8. (Default value: 0)
Treble Level Adjust to 3 steps of -8
↔
0
↔
+8. (Default value: 0)
HPF Front/Rear
[VOL] knob and
[FM] / [AM] key
Adjust to 2 steps of Through
↔
180Hz (or 220Hz). (Default value: Through)
LPF Sub woofer Adjust to 2 steps of Through
↔
60Hz (or 50Hz). (Default value: Through)
Sub Woofer Phase Adjust to 2 steps of Reverse
↔
Normal. (Default value: Normal)
Volume Offset
Adjust to 2 steps of -8
↔
0. (Default value: 0)
Adjust to 3 steps of -8
↔
0
↔
+8. (Default value: 0) (AUX)
Loudness Adjust to 2 steps of OFF
↔
ON. (Default value: OFF)
2ZONE Adjust to 2 steps of OFF
↔
ON. (Default value: 0)
∗
Continuous forwarding by remote controller is prohibited.
∗
Bass f/Bass Q/Bass EXT/Middle f/Middle Q/Treble f does not appear in the audio adjustment.
■
S·E (eala) related test mode
Procedure Note
Press [S·E] key briefl y (main unit) Run the test with the following order of sequence. (
q
→
w
→
e
→
r
→
t
→
q
→
···)
Order of
sequence
Setting Value
Display
Change the assigned Track and VOL at the
same time when setting up the S·E
S·E (Eala) LV S·E (Eala) Bass
q
Off Off S·E OFF VOL=30
w
High Off LV High
e
Low Off LV Low
r
Off High Bass High
t
Off Low Bass Low
∗
Note: For 5 seconds after the establishment of CD source, the switching of S·E is not displayed. (However, the value changes when the key is
pressed.)
■
Menu-related test mode
Procedure Note
Press [M.JOG] key briefl y (main unit)
[DNPP/SBF] key, [DIRECT] key (remote control)
Continuous forwarding by remote control is prohibited.
■
Dual Zone-related test mode
Procedure Note
Press and hold [ATT/
■
TI] key in other mode than Standby (main unit) To turn ON/OFF Dual Zone. (Default value: OFF)
■
Backup current measurement
Procedure Note
While ACC OFF (Back Up ON), Reset
MUTE terminal is turned OFF after 2 seconds, not after 15 seconds. (During this time, the CD
mechanism does not function.) Turning the terminal OFF in 2 seconds makes the system to be
in low power consumption condition.
TEST MODE
