Kenwood eXcelon KAC-X1R User Manual

English 5
POWER IN
SPEAKER OUTPUT
LINE OUT FILTER
REMOTE RESET LINE IN LINE OUT
ONOFF
FUSE (25As3)
25 25
25
POWER IN
SPEAKER OUTPUT
LINE OUT FILTER
REMOTE RESET LINE IN LINE OUT
ONOFF
FUSE (25As3)
25
25
25
POWER IN
SPEAKER OUTPUT
LINE OUT FILTER
REMOTE RESET LINE IN LINE OUT
ONOFF
FUSE (25As3)
25 25
25
LINE OUT FILTER
ONOFF
LINE OUT FILTER
ONOFF
4
0.2(MAX)(MIN)5
3
2
1
0.5
INPUT
SENSITIVITY(V)
4
0.2(MAX)(MIN)5
3
2
1
0.5
INPUT
SENSITIVITY(V)
LINE OUT FILTER
ONOFF
4
0.2(MAX)(MIN)5
3
2
1
0.5
INPUT
SENSITIVITY(V)
40 200
150
100
70
LPF
FREQUENCY(Hz)
LPF
ON
OFF
40 200
150
100
70
LPF
FREQUENCY(Hz)
LPF
ON
OFF
40 200
150
100
70
LPF
FREQUENCY(Hz)
LPF
ON
OFF
Remote cable
Remote controller
CENTER UNIT
(CD receiver, etc.)
You can control the Bass boost level of the second
and subsequent Slave amplifiers simultaneously
from the Master amplifier.
The volume level of each amplifier is determined
by the setting of the Master amplifier (INPUT
SENSITIVITY, boost level of the remote controller).
Setting the Master amplifier
1. Adjust the "INPUT SENSIVITY" to the output of
the center unit to be connected.
2. Set the LPF frequency and Bass boost level.
3. Turn the "LINE OUT FILTER" switch "ON".
Setting the Slave amplifier
1. Turn the "LINE OUT FILTER" switch "OFF".
2. Adjust the "INPUT SENSIVITY".
• To adjust the Slave amplifier to the same
volume as the Master amplifier, adjust the
"INPUT SENSIVITY" to "0.2 V (max.)".
2CAUTION
• Before connecting the remote controller
cables, always turn the Bass boost level knob
all the way to the left.
* Commercially available parts
■ Multi Amplifier with Remote cable connection ( Accessory of KAC-PS1D. Optional accessory for KAC-X1R.)
Master amplifier
Slave amplifier
Slave amplifier
Power control wire
Extension wire*
RCA cable*
RCA cable*
