KDC-1016/115S
23
PARTS LIST
K:KDC-115S M1:KDC-1016
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No. Parts No. Description
A
d
d
N
e
w
Dest
inati
on
202 1D ∗ A52-0757-02 TOP PLATE
PA1 3C ∗ A64-1938-02 PANEL ASSY K
PA1 3C ∗ A64-1939-02 PANEL ASSY M1
207 1C B07-2181-02 ESCUTCHEON
208 3C ∗ B10-3146-03 FRONT GLASS
- B46-0100-50 WARRANTY CARD
- B58-1344-04 CAUTION CARD K
- ∗ B64-1543-00
INST.MANUAL (ENG,FRE,SPA,POR)
K
- ∗ B64-1544-00 INST.MANUAL (ENG,CHI) M1
- ∗ B64-1592-00 INST.MANUAL (ARABIC) M1
211 1C D10-3031-04 LEVER
215 2C ∗ E29-1801-03 CONDUCTIVE RUBBER
DC1 1C E30-4783-05 DC CORD K
DC2 1C E30-4784-05 DC CORD M1
FC1 2C ∗ E39-0343-05 FLAT CABLE
F1 2D F52-0006-05 FUSE(MINI BLADE TYPE) (10A)
F1 2D F52-0011-05 FUSE(MINI BLADE TYPE) (10A)
- ∗ H10-4690-12 POLYSTYRENE FOAMED FIXTURE
- H25-0329-04 PROTECTION BAG (280X450X0.03)
- H25-0337-04 PROTECTION BAG (180X300X0.03)
- ∗ H54-1616-03 ITEM CARTON CASE K
- ∗ H54-1618-03 ITEM CARTON CASE M1
223 3C ∗ J19-4984-02 HOLDER
224 1C J21-9491-03 MOUNTING HARDWARE ASSY
225 1C J54-0606-04 STAY
228 3C ∗ K24-3548-04 KNOB (SRC)
229 3C ∗ K25-1104-03 KNOB (PRESET1-6)
230 3C ∗ K25-1105-03 KNOB (BAND,UP,CLK,AUTO,RES)
231 3C ∗ K25-1107-03 KNOB (VOL,ATT,DOWN,EJECT)
234 1C N99-1632-05 SCREW SET
A 3D N30-3004-46 PAN HEAD MACHINE SCREW
B 3C N80-2006-46 PAN HEAD TAPTITE SCREW
C 2C N82-2006-46 BINDING HEAD TAPTITE SCREW
D 2C N83-3005-46 PAN HEAD TAPTITE SCREW
ME1 1C ∗ X92-3690-00 CD MECHANISM ASSY
D1 -12 B30-1565-05 LED(1608,PG)
CN1 E40-9453-05 SOCKET FOR PIN ASSY (12P)
R1 -4 RK73EB2B331J CHIP R 330 J 1/8W
241 2D ∗ A33-0621-12 REFLECTOR
ED1 ∗ B38-1023-05 LIQUID CRYSTAL
PL1 ,2 B30-1418-15 LAMP (5.5V 125MA,GR)
C2 C90-5235-05 ELECTRO 2200UF 16WV
C3 C90-2926-05 ELECTRO 220UF 16WV
C4 CK73GB1H103K CHIP C 0.010UF K
C5 C90-2594-05 ELECTRO 10UF 10WV
KDC-1016/115S
Ref. No. Parts No. Description
Dest
inati
on
C6 CE04CW0J101M ELECTRO 100UF 6.3WV
C7 CE04CW1C101M ELECTRO 100UF 16WV
C8 ,9 CE04CW1A101M ELECTRO 100UF 10WV
C11 CK73FB1H103K CHIP C 0.010UF K
C12 CK73GB1H103K CHIP C 0.010UF K
C14 C90-2598-05 ELECTRO 3.3UF 25WV
C15 CK73FB1E683K CHIP C 0.068UF K
C16 C90-2602-05 ELECTRO 0.10UF 50WV
C18 CK73GB1H103K CHIP C 0.010UF K
C22 CK73GB1C104K CHIP C 0.10UF K
C24 CK73FB1H103K CHIP C 0.010UF K
C25 C90-2597-05 ELECTRO 10UF 16WV
C26 CE04CW1A101M ELECTRO 100UF 10WV
C27 -30 C90-5296-05 ELECTRO 0.22UF 50WV
C31 C90-2935-05 ELECTRO 1.0UF 50WV
C32 C90-2608-05 ELECTRO 1.0UF 50WV
C35 ,36 C90-2597-05 ELECTRO 10UF 16WV
C37 ,38 C90-2610-05 ELECTRO 2.2UF 50WV
C42 CC73FCH1H151J CHIP C 150PF J
C43 CK73FB1E333K CHIP C 0.033UF K
C44 CK73FB1H153K CHIP C 0.015UF K
C45 CK73FB1C224K CHIP C 0.22UF K
C46 CK73FB1C823K CHIP C 0.082UF K
C49 C90-2608-05 ELECTRO 1.0UF 50WV
C50 CE04CW1A470M ELECTRO 47UF 10WV
C51 CK73GB1H103K CHIP C 0.010UF K
C52 CK73FB1C104K CHIP C 0.10UF K
C53 CK73FB1C224K CHIP C 0.22UF K
C55 CE04CW1A470M ELECTRO 47UF 10WV
C58 CE04CW1A470M ELECTRO 47UF 10WV
C59 CK73FB1C104K CHIP C 0.10UF K
C60 ,61 CK73FB1H103K CHIP C 0.010UF K
C80 CK73FB1H103K CHIP C 0.010UF K
C100,101 CC73GCH1H220J CHIP C 22PF J
C102,103 CK73FB1H103K CHIP C 0.010UF K
CN1 E40-9550-05 FLAT CABLE CONNECTOR (22P)
J1 2D E58-0863-15
RECTANGULAR RECEPTACLE (16P)
J2 2D E63-0852-05 PIN JACK (2P)
J3 2D E04-0312-05 RF COAXIAL CABLE RECEPTACLE
J4 2D E40-9452-05 PIN ASSY (12P)
L2 ,3 L40-4795-91 SMALL FIXED INDUCTOR(4.7UH,J)
L7 L40-4795-91 SMALL FIXED INDUCTOR(4.7UH,J)
L8 L33-1123-05 LINE FILTER COIL
L9 L40-4795-91 SMALL FIXED INDUCTOR(4.7UH,J)
L10 2D ∗ L33-1142-05 CHOKE COIL
X1 L77-2032-05 CRYSTAL RESONATOR (8.0MHZ)
D 1D N83-3005-46 PAN HEAD TAPTITE SCREW
E 1D N35-3010-46
BINDING HEAD MACHINE SCREW
F 1D N80-3008-46 PAN HEAD TAPTITE SCREW
G 1D N83-3020-46 PAN HEAD TAPTITE SCREW
H 2D N86-2606-46 BINDING HEAD TAPTITE SCREW
R1 RK73GB1J223J CHIP R 22K J 1/16W
R2 RK73GB1J101J CHIP R 100 J 1/16W
R3 RK73FB2A103J CHIP R 10K J 1/10W
A
d
d
N
e
w
SWITCH UNIT (X13-9660-10)
ELECTRIC UNIT (X25-8420-XX)
indicates safety critical components.
!
!
!
!
!
!
!
To Next Page
