Kenwood KDC-2031SA User Manual

27
KDC-2031SA/2031SAY
KDC-2031SG/2031SGY
Indicates safety critical components.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
E4 : KDC-2031SA E5 : KDC-2031SG E6 : KDC-2031SGY E7 : KDC-2031SAY
(E : Europe K : North America M : Other Areas W : Without Europe)
PARTS LIST
C1 C93-1215-05 CERAMIC 10UF K
C2 CK73FB1A225K CHIP C 2.2UF K
C3 CK73GB0J105K CHIP C 1.0UF K
C5 CC73GCH1H020C CHIP C 2.0PF C
C6 CC73GCH1H390J CHIP C 39PF J
C7 CK73GB1C104K CHIP C 0.10UF K
C8 CK73GB0J105K CHIP C 1.0UF K
C9 CK73GB1H472K CHIP C 4700PF K
C10 CK73GB1C333K CHIP C 0.033UF K
C11 CK73GB1H682K CHIP C 6800PF K
C12 CK73GB1H332K CHIP C 3300PF K
C13 CC73GCH1H271J CHIP C 270PF J
C14 CK73GB1H472K CHIP C 4700PF K
C15 CK73GB1H222K CHIP C 2200PF K
C16 CC73GCH1H331J CHIP C 330PF J
C17,18 CK73GB1C104K CHIP C 0.10UF K
C31-34 CK73GB1C104K CHIP C 0.10UF K
C36 CK73FB1A225K CHIP C 2.2UF K
C37-39 CK73GB1H103K CHIP C 0.010UF K
C40 CK73GB1H153K CHIP C 0.015UF K
C41 CK73GB1H102K CHIP C 1000PF K
C42 CK73GB1E473K CHIP C 0.047UF K
C43 CK73GB1H222K CHIP C 2200PF K
C44 CK73GB1H102K CHIP C 1000PF K
C45-47 CK73GB1C104K CHIP C 0.10UF K
C48 CK73GB1H682K CHIP C 6800PF K
C49 CK73GB1H152K CHIP C 1500PF K
C50 CK73GB1H472K CHIP C 4700PF K
C51 CK73GB1H681K CHIP C 680PF K
C52 CK73GB1C104K CHIP C 0.10UF K
C61 CK73FB1A225K CHIP C 2.2UF K
C62 CK73GB1C104K CHIP C 0.10UF K
C71,72 CK73GB1H471K CHIP C 470PF K
C73,74 CC73GCH1H680J CHIP C 68PF J
C75,76 CK73GB1H222K CHIP C 2200PF K
C77,78 CK73GB1C104K CHIP C 0.10UF K
C100-102 CK73GB1H102K CHIP C 1000PF K
CN1 E41-2068-05 FLAT CABLE CONNECTOR
CN1 E41-2085-15 FLAT CABLE CONNECTOR
CN2 E41-2083-05 FLAT CABLE CONNECTOR
X1 L78-0851-05 RESONATOR (16.934MHZ)
CP1 RK74GA1J101J CHIP-COM 100 J 1/16W
CP2 RK74GB1J101J CHIP-COM 100 J 1/16W
CP3 RK74GB1J182J CHIP-COM 1.8K J 1/16W
CP4 RK74GB1J472J CHIP-COM 4.7K J 1/16W
CP5 RK74GB1J104J CHIP-COM 100K J 1/16W
R1 RK73GB2A910J CHIP R 91 J 1/10W
R2,3 RK73GB2A562J CHIP R 5.6K J 1/10W
R4 RK73FB2B100J CHIP R 10 J 1/8W
R5,6 RK73GB2A332J CHIP R 3.3K J 1/10W
R7 RK73GB2A362J CHIP R 3.6K J 1/10W
R8 RK73GB2A273J CHIP R 27K J 1/10W
R9 RK73GB2A392J CHIP R 3.9K J 1/10W
R10 RK73GB2A104J CHIP R 100K J 1/10W
R11 RK73GB2A333J CHIP R 33K J 1/10W
R12 RK73GB2A244J CHIP R 240K J 1/10W
R13 RK73GB2A914J CHIP R 910K J 1/10W
R14 RK73GB2A104J CHIP R 100K J 1/10W
R15 RK73GB2A472J CHIP R 4.7K J 1/10W
R31 RK73GB2A273J CHIP R 27K J 1/10W
R32 RK73GB2A103J CHIP R 10K J 1/10W
R33 RK73GB2A183J CHIP R 18K J 1/10W
R34 RK73GB2A103J CHIP R 10K J 1/10W
R35 RK73GB2A393J CHIP R 39K J 1/10W
R36 RK73GB2A103J CHIP R 10K J 1/10W
R37 RK73GB2A622J CHIP R 6.2K J 1/10W
R38 RK73GB2A224J CHIP R 220K J 1/10W
R39 RK73GB2A104J CHIP R 100K J 1/10W
R40 RK73GB2A821J CHIP R 820 J 1/10W
R41 RK73GB2A473J CHIP R 47K J 1/10W
R42 RK73GB2A472J CHIP R 4.7K J 1/10W
R43 RK73GB2A102J CHIP R 1.0K J 1/10W
R44,45 RK73GB2A103J CHIP R 10K J 1/10W
R46 RK73GB2A273J CHIP R 27K J 1/10W
R47 RK73GB2A222J CHIP R 2.2K J 1/10W
R48 RK73GB2A103J CHIP R 10K J 1/10W
R49 RK73GB2A473J CHIP R 47K J 1/10W
R50 RK73GB2A392J CHIP R 3.9K J 1/10W
R51 RK73GB2A103J CHIP R 10K J 1/10W
R52,53 RK73GB2A472J CHIP R 4.7K J 1/10W
R71 RK73GB2A133J CHIP R 13K J 1/10W
R72 RK73FB2B201J CHIP R 200 J 1/8W
R81,82 RK73FB2B183J CHIP R 18K J 1/8W
R83,84 RK73FB2B203J CHIP R 20K J 1/8W
R85,86 RK73FB2B123J CHIP R 12K J 1/8W
R87,88 RK73FB2B331J CHIP R 330 J 1/8W
R89,90 RK73GB2A392J CHIP R 3.9K J 1/10W
R91,92 RK73GB2A562J CHIP R 5.6K J 1/10W
R100 RK73GB2A100J CHIP R 10 J 1/10W
S1,2 S68-0863-05 PUSH SWITCH
S3 S68-0862-05 PUSH SWITCH
D1 DAN202U DIODE
D2 MAZS0510L ZENER DIODE
D3 DA204U DIODE
IC1
✽ AN22002A-V ANALOGUE IC
IC2 MN6627771KP MOS-IC
IC3 BA5824FP-F ANALOGUE IC
IC4 NJM4580M1-ZB ANALOGUE IC
Q1 2SB0970 TRANSISTOR
Q2 2SA1362(Y) TRANSISTOR
Q3 DTC124EUA DIGITAL TRANSISTOR
Q4 DTA143XUA DIGITAL TRANSISTOR
Q5 2SC4081 TRANSISTOR
Q6 2SA1576A TRANSISTOR
CD PLAYER UNIT (X32-5750-00)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood KDC-2031SA Specifications

Power

maximum power	45W x 4
power (DIN45324, +B=14.4V)	28W x 4
operating voltage	14.4V
current consumption	10A

Frequency and Sensitivity

frequency range (FM)	87.5MHz~108.0MHz
frequency range (AM)	531kHz~1611kHz
frequency range (LW)	153kHz~281kHz
usable sensitivity (FM, S/N : 26dB)	0.7µV/75Ω
quieting sensitivity (FM, S/N : 46dB)	1.6µV/75Ω
usable sensitivity (AM, S/N : 20dB)	25µV
usable sensitivity (LW, S/N : 20dB)	45µV

Weight and Dimensions

width	182mm
height	53mm
depth	155mm
weight	1.40kg (3.1 lbs)
