30
KDC-205/CR, 226
KDC-2026, 3026/R
Indicates safety critical components.
✽ New parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
K2 : KDC-205 K4 : KDC-205CR M : KDC-3026
M1: KDC-2026 M2: KDC-226 M3: KDC-3026R
201 1C A02-1486-13 PLASTIC CABINET ASSY
205 2C A22-2863-03 SUB PANEL ASSY
207 2C
✽
A46-1796-01 REAR COVER
208 1D A52-0804-02 TOP PLATE
PA1 3C
✽
A64-3149-02 PANEL ASSY K2
PA1 3C
✽
A64-3161-02 PANEL ASSY M3
PA1 3C
✽
A64-3162-02 PANEL ASSY M
PA1 3C
✽
A64-3163-02 PANEL ASSY M1
PA1 3C
✽
A64-3164-02 PANEL ASSY M2
PA1 3C
✽
A64-3304-02 PANEL ASSY K4
- B46-0100-50 WARRANTY CARD
- B46-0606-04 ID CARD
- B58-1365-04 CAUTION CARD
-
✽
B64-2670-00
INST. MANUAL (ENG,FRA,SPA,POR)
K2
-
✽
B64-2671-00 INST. MANUAL (ENG,T-CHI)
MM1M2
-
✽
B64-2672-00 INST. MANUAL (ARABIC)
MM1M2
-
✽
B64-2729-00 INST. MANUAL (ENG,T-CHI) M3
-
✽
B64-2730-00 INST. MANUAL (ARABIC) M3
-
✽
B64-2738-00 INST. MANUAL (ENG,SPA,POR) K4
210 1C B07-3001-02 ESCUTCHEON K4M2
210 1C
✽
B07-3097-02 ESCUTCHEON K2
210 1C
✽
B07-3098-02 ESCUTCHEON M
210 1C
✽
B07-3098-02 ESCUTCHEON M1M3
211 3C
✽
B10-4443-01 FRONT GLASS K2
211 3C
✽
B10-4455-01 FRONT GLASS M3
211 3C
✽
B10-4456-01 FRONT GLASS M
211 3C
✽
B10-4457-01 FRONT GLASS M1
211 3C
✽
B10-4458-01 FRONT GLASS M2
211 3C
✽
B10-4547-01 FRONT GLASS K4
213 1C D10-4446-03 LEVER
214 1C D10-4447-03 LEVER
215 1C D10-4589-04 LEVER
216 1C D21-2329-04 SHAFT
218 1C
✽
E29-1964-02 CONDUCTIVE RUBBER
219 1D E30-6229-05 CORD WITH PINPLUG M
DC1 1C
✽
E30-6132-15 DC CORD M3
DC1 1C
✽
E30-6286-05 DC CORD M3
DC2 1C
✽
E30-6322-05 DC CORD K2
DC2 1C
✽
E30-6322-05 DC CORD K4M
DC2 1C
✽
E30-6322-05 DC CORD M1M2
DC2 1C
✽
E30-6323-05 DC CORD K2
DC2 1C
✽
E30-6323-05 DC CORD K4M
DC2 1C
✽
E30-6323-05 DC CORD M1M2
FC1 2D E39-0476-05 FLAT CABLE (22PIN)
223 1D F29-0626-04 INSULATING COVER M
F1 2D F52-0006-05 FUSE (MINI BLADE TYPE 10A)
F1 2D
✽
F52-0023-05 FUSE (MINI BLADE TYPE 10A)
224 1C G01-2987-04 TORSION COIL SPRING
225 1C G01-3096-04 EXTENSION SPRING
226 3C G01-3149-04 COMPRESSION SPRING
- H10-4856-12
POLYSTYRENE FOAMED FIXTURE
- H25-0329-04
PROTECTION BAG (280X450X0.03)
- H25-0337-04
PROTECTION BAG (180X300X0.03)
-
✽
H54-2966-03 ITEM CARTON CASE K2
-
✽
H54-2967-03 ITEM CARTON CASE M3
-
✽
H54-2968-03 ITEM CARTON CASE M
-
✽
H54-2969-03 ITEM CARTON CASE M1
-
✽
H54-2970-03 ITEM CARTON CASE M2
-
✽
H54-3121-03 ITEM CARTON CASE K4
229 1C J21-9716-03 MOUNTING HARDWARE ASSY
232 3C
✽
K24-4098-04 KNOB (SRC)
233 3C
✽
K24-4099-04 KNOB (Q-AUDIO)
234 3C
✽
K24-4101-04 KNOB (RELESE)
235 3C
✽
K24-4096-04 KNOB (VOL.UP)
236 3C
✽
K24-4097-04 KNOB (VOL.DOWN)
237 3C
✽
K25-1589-03 KNOB (PRESET1-6)
238 3C
✽
K25-1590-03 KNOB (EJECT/ATT)
239 3C
✽
K25-1613-03 KNOB (FM/AM)
240 3C
✽
K25-1614-03 KNOB (SEEK)
242 1C N84-4016-46 PAN HEAD TAPTITE SCREW
243 1C N99-1719-05 SCREW SET
A2DN30-3008-46 PAN HEAD MACHINE SCREW
B2DN80-2006-46 PAN HEAD TAPTITE SCREW
C2DN80-2008-45 PAN HEAD TAPTITE SCREW
D2DN83-3005-46 PAN HEAD TAPTITE SCREW
H2DN29-0205-04 RETAINING RING
244 1C T90-0523-05 ANTENNA ADAPTOR M3
DME1 1D
✽
X92-4840-00
MECHANISM ASSY (DXM-6200W)
245 2C
✽
B11-1436-04 OPTICAL DIFFUSER M3
246 2C
✽
B11-1437-04 REFLECTION SHEET M3
248 2C
✽
B19-2242-03 LIGHTING BOARD M3
D1 B30-1633-05 LED (WHITE) M3
D2 B30-1567-05 LED (1608,RED) M3
D3,4 B30-1564-05 LED (1608,BLUE) M3
D11-19 B30-1567-05 LED (1608,RED) M3
D21-29 B30-1533-05 LED (1608,PG) M3
ED1 2C
✽
B38-1145-05 LIQUID CRYSTAL M3
C1 CK73GB1H102K CHIP C 1000PF K M3
C2 CK73GB1H103K CHIP C 0.010UF K M3
C3,4 CK73GB1E473K CHIP C 0.047UF K M3
C5 CK73FB1A225K CHIP C 2.2UF K M3
C11-13 CK73GB1H103K CHIP C 0.010UF K M3
249 2C
✽
E29-1965-04 CONDUCTIVE RUBBER M3
250 2C
✽
E29-1966-04 CONDUCTIVE RUBBER M3
J1 E59-0828-05 RECTANGULAR PLUG (15PIN) M3
R1 RK73GB2A563J CHIP R 56K J 1/10W M3
R2 RK73GB2A4R7J CHIP R 4.7 J 1/10W M3
R3 RK73GB2A472J CHIP R 4.7K J 1/10W M3
R4 RK73GB2A473J CHIP R 47K J 1/10W M3
R5 RK73GB2A102J CHIP R 1.0K J 1/10W M3
R6-8 RK73GB2A471J CHIP R 470 J 1/10W M3
KDC-205/CR, KDC-226, KDC-2026, KDC-3026/R
