KDC-205/CR, 226
KDC-2026, 3026/R
Indicates safety critical components.
✽ New parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
W534 R92-1252-05 CHIP R 0 OHM J 1/16W
W578 R92-1252-05 CHIP R 0 OHM J 1/16W M3
W601 R92-1252-05 CHIP R 0 OHM J 1/16W
D1 1N5393G-M6 DIODE
D3 IMSA-6801 SURGE ABSORBER
D10 MA4068(N)-M ZENER DIODE
D11 D1F60 DIODE
K4MM1
D11 D1F60 DIODE M2M3
D12 AM01ZNF DIODE
K4MM1
D12 AM01ZNF DIODE M2M3
D13 D1F60 DIODE
D14 AM01ZNF DIODE
D20 MA4068(N)-M ZENER DIODE
D30 MA4047-M ZENER DIODE M3
D40 1SS133 DIODE
D50 DAN202U DIODE
D51 MA4082(N)-L ZENER DIODE
D70 MA4068(N)-M ZENER DIODE
D101 1SS133 DIODE
D102 B30-1567-05 LED (1608,RED)
D103 DA204U DIODE
D106 MA4062-L ZENER DIODE
D108 MA4062-L ZENER DIODE K2
D108 MA4062-L ZENER DIODE K4M
D108 MA4062-L ZENER DIODE M1M2
D108,109 MA4062-L ZENER DIODE M3
D110 UDZS12B ZENER DIODE
D201,202 MA4068(N)-M ZENER DIODE
D251-253 1SS133 DIODE
D261-263 AM01ZNF DIODE K2
D261-263 AM01ZNF DIODE MM1
D261-263 AM01ZNF DIODE M3
D264 D1F60 DIODE K2
D264 D1F60 DIODE MM1
D264 D1F60 DIODE M3
D264 S1J DIODE K2
D264 S1J DIODE MM1
D264 S1J DIODE M3
D265,266 AM01ZNF DIODE K2
D265,266 AM01ZNF DIODE MM1
D265,266 AM01ZNF DIODE M3
D267,268 D1F60 DIODE K2
D267,268 D1F60 DIODE MM1
D267,268 D1F60 DIODE M3
D267,268 S1J DIODE K2
D267,268 S1J DIODE MM1
D267,268 S1J DIODE M3
D401,402 MA4068(N)-M ZENER DIODE MM1
D401,402 MA4068(N)-M ZENER DIODE M3
D403-405 MA4062-L ZENER DIODE MM1
D403-405 MA4062-L ZENER DIODE M3
D407-410 MA4062-L ZENER DIODE MM1
D407-410 MA4062-L ZENER DIODE M3
D411 MA3062WA ZENER DIODE MM1
D411 MA3062WA ZENER DIODE M3
D501 RN739F DIODE
D503 RN739F DIODE
D504-506 KV1720S
VARIABLE CAPACITANCE DIODE
IC1
✽
UPD780058GC554 MICROCONTROLLER IC M3
IC1
✽
UPD780058GC555 MICROCONTROLLER IC K2
IC1
✽
UPD780058GC555 MICROCONTROLLER IC K4M
IC1
✽
UPD780058GC555 MICROCONTROLLER IC M1M2
IC4 TDA7386 ANALOGUE IC K4M2
IC4 TDA7560 ANALOGUE IC K2
IC4 TDA7560 ANALOGUE IC MM1
IC4 TDA7560 ANALOGUE IC M3
IC6 TDA7479AD ANALOGUE IC M3
IC7 BA4911-V4 ANALOGUE IC
IC8 HD74HC27FP-E MOS-IC
IC10
✽
TDA7513T ANALOGUE IC
IC11 PST3435UL MOS-IC
IC12 BR24C01AF-W ROM IC
IC12 M24C01-WMN6T ROM IC
IC12 S-24CS02AFJ-TB MEMORY IC
Q10 2SC4081 TRANSISTOR
Q20 2SC4081 TRANSISTOR
Q40 DTA124EUA DIGITAL TRANSISTOR
Q50 2SA1036K TRANSISTOR
Q51 UMC2N TRANSISTOR
Q53 UMC2N TRANSISTOR
MM1M2
Q55 2SD2375 TRANSISTOR
Q70 2SC4081 TRANSISTOR
Q101 2SC4081 TRANSISTOR
Q102 DTA114YUA DIGITAL TRANSISTOR
Q201 2SC4081 TRANSISTOR M3
Q223,224 DTC143TUA DIGITAL TRANSISTOR
Q251 DTC114YUA DIGITAL TRANSISTOR K4M2
Q252 UMG4N TRANSISTOR M3
Q253 UMA1N TRANSISTOR M3
Q501 CPH5905 TRANSISTOR
Q502 3SK126 DUAL FET
Q503 2SC4081 TRANSISTOR M3
TH1
✽
PRF21BE471QB2 POSITIVE RESISTOR
C221,222 C90-5574-05 ELECTRO 10UF 16WV M
CN90 E40-3238-05 PIN ASSY M
CN91 E40-3249-05 PIN ASSY M
W101,102 E31-0001-00 JUMPER WIRE M
R221,222 RK73GB2A271J CHIP R 270 J 1/10W M
R225,226 RK73GB2A303J CHIP R 30K J 1/10W M
R229,230 RD14BB2C101J RD 100 J 1/6W M
Q221,222 DTC143TUA DIGITAL TRANSISTOR M
Q225 DTA124EUA DIGITAL TRANSISTOR M
21BA10-4827-22 CHASSIS
51B
✽
D10-4576-63 ARM ASS’Y
MECHANISM ASSY (X92-4840-00)
DAUGHTER UNIT (X89-2590-10)
ELECTRIC UNIT (X34-3100-21/X34-3110-xx)
K2 : KDC-205 K4 : KDC-205CR M : KDC-3026
M1: KDC-2026 M2: KDC-226 M3: KDC-3026R
