3
BASICS
To On the faceplate On the remote control
Turn on the power
Press
.
• Press and hold to turn off the power.
*
2
Press and hold SRC to turn off the power.
( Pressing SRC does not turn on the power. )
Adjust the volume Turn the volume knob. Press
or .
• Press and hold
to continuously increase the
volume to 15.
Press ATT during playback to attenuate the sound.
• Press again to cancel.
Select a source
Press
repeatedly.
Press SRC repeatedly.
Change the display information*
3
Press DISP repeatedly.
( 34, 35)
( Not available )
*
1
Only for / / / .
*
2
For : The power will automatically turn off after 20minutes when in standby mode (Auto Power Off).
*
3
For : You can also turn off the display information by pressing
DISP
repeatedly.
Faceplate
How to resetAttach Detach
Remote control (RC-406)
(supplied for )
ENGLISH
Display window
Pull out the insulation sheet
when using for the first time.
How to replace the battery
Remote sensor (Do not expose to
bright sunlight.)
Volume
knob
Detach
button
/ : Can be remotely
controlled with an optionally purchased remote control.
/ / : Remote
control functions are not available.
Flashes when the unit
enters searching status.
*
1
Lights up when
Bluetooth
connection is
established.
*
1
( 18)
: USB cable
from the rear of the unit.
Reset the unit
within 5 seconds
after detaching
the faceplate.
