Kenwood M-A100 Service Manual

M-A100/A300
2
CONTENTS / ACCESSORIES
Contents
CONTENTS / ACCESSORIES ....................................2
DISASSEMBLY FOR REPAIR.....................................3
ADJUSTMENT.............................................................4
PC BOARD ..................................................................5
SCHEMATIC DIAGRAM ..............................................9
EXPLODED VIEW .....................................................15
PARTS LIST...............................................................16
SPECIFICATIONS .....................................................21
Accessories
Parallel cord ..................(1)
(E30-2857-05)
AC plug adaptor ............(1)
(E03-0115-05)
Use to adapt the plug on the power card
to the shape of the wall outlet.
(Accessory only for regions where use is
necessary.)
1p~3p/19p~22p 97.6.2 4:11 PM y[W 2

Kenwood M-A100 Specifications

General

Brand	Kenwood
Model	M-A100
Category	Amplifier
Language	English
