NX-5000 Remote Configuration [Initial Setup Instruction]
Page | 5
4) Click the “OK” button of the following window displayed after writing is finished.
5) Confirm the firmware checksum in the LCD display to insure that the appropriate firmware has been written.
(If checksum is incorrect, then repeat from procedure 1).
6) Reboot the radio.
3. Authenticate Radio Feature License “KWD-5004MR”*
* This is necessary only for radios with S/No. B5900000 or earlier.
4. Check Firmware Version and Radio Feature License
1) Confirm that the radio’s data has the correct Firmware Version
and Activated Features using the “Transceiver Information”
of KPG-D1N.
[Firmware Version] “K 1.62.00” or later
[Activated Features］“KWD-5004MR” (Multi Receive)
2) Power off the radio and remove Head from Deck.
<Transceiver Information on KPG-D1 >
