Kenwood NX-5200 K2 User Manual

1-4 (No.RA018<Rev.002>)
*25 and 30 kHz are not included in the models sold in the USA or US territories.
Analog measurements made per TIA 603 and specifications shown are typical.
P25 Digital measurements made per TIA 102CAAA and specifications shown are typical.
JVC KENWOOD Corporation reserves the right to change specifications without prior notice or obligation.
FM Hum & Noise Analog @ 25 kHz 45dB
Analog @ 12.5 kHz 40dB
Audio Distortion Less than 2%
Modulation 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D, 8K10F1W,
8K30F1E, 8K30F1D, 8K30F7W, 4K00F1E,4K00F1D,
4K00F7W, 4K00F2D

Kenwood NX-5200 K2 Specifications

General

Frequency Range	136-174 MHz
Operating Temperature	-30°C to +60°C
Operating Voltage	7.5V DC ±20%
GPS	Optional
Ingress Protection	IP67
MIL-STD	MIL-STD-810 C/D/E/F/G
Power Output	5W
Waterproof	Yes
Channel Spacing	12.5 kHz / 25 kHz
Digital Protocol	NXDN
Modulation	16K0F3E, 11K0F3E
