Kenwood R-SE9T Service Manual

20
PARTS LIST
R-SE9/SE9T
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
C1 CE04KW1C470M ELECTRO 47UF 16WV
C2 CE04KW1H010M ELECTRO 1.0UF 50WV
C3 -8 CK73FB1H103K CHIP C 0.010UF K
C9 C91-0769-05 CERAMIC 0.010UF K
C30 CK73EB1E473K CHIP C 0.047UF K
C31 CE04KW1C470M ELECTRO 47UF 16WV
C32 CK73FB1H103K CHIP C 0.010UF K
C33 CE04KW1C100M ELECTRO 10UF 16WV
C34 CK73EB1E104K CHIP C 0.10UF K
C35 CE04KW1C100M ELECTRO 10UF 16WV
C36 CK73FB1E473K CHIP C 0.047UF K
C37 CK73EF1E105Z CHIP C 1.0UF Z
C38 C90-3217-05 ELECTRO 10UF 10WV
C40 C90-3253-05 ELECTRO 1.0UF 50WV
C41 C90-3251-05 ELECTRO 0.47UF 50WV
C42 C90-3240-05 ELECTRO 2.2UF 35WV
C43 CE04KW1HR47M ELECTRO 0.47UF 50WV
C44 CK73FB1E473K CHIP C 0.047UF K
C45 CC73FCH1H220J CHIP C 22PF J
C46 CE04KW1A101M ELECTRO 100UF 10WV
C47 CK73FB1H682K CHIP C 6800PF K
C48 CC73FSL1H101J CHIP C 100PF J
C49 C90-3253-05 ELECTRO 1.0UF 50WV
C50 CK73FB1H102K CHIP C 1000PF K
C51 ,52 C90-3217-05 ELECTRO 10UF 10WV
C53 ,54 CK73FB1H273K CHIP C 0.027UF K
C55 ,56 C90-3240-05 ELECTRO 2.2UF 35WV
C57 ,58 CK73FB1H682K CHIP C 6800PF K
C60 CK73FB1E104K CHIP C 0.10UF K
C61 CK73FB1H103K CHIP C 0.010UF K
C63 CC73FCH1H040C CHIP C 4.0PF C
C64 CK73FB1H333K CHIP C 0.033UF K
C66 CC73FCH1H060D CHIP C 6.0PF D
C67 CC73FCH1H220J CHIP C 22PF J
C68 CC73FSL1H020C CHIP C 2.0PF C
C69 CK73FB1H103K CHIP C 0.010UF K
C70 CC73FSL1H101J CHIP C 100PF J
C81 CC73FCH1H220J CHIP C 22PF J
C82 CC73FCH1H270J CHIP C 27PF J
C84 CK73FB1H102K CHIP C 1000PF K
C85 C91-0745-05 CERAMIC 100PF K
C86 C91-0757-05 CERAMIC 1000PF K
C87 CE04KW1A470M ELECTRO 47UF 10WV
C89 CE04KW1C470M ELECTRO 47UF 16WV
C90 CE04KW1H2R2M ELECTRO 2.2UF 50WV
C91 CQ93FMG1H223J MYLAR 0.022UF J
C92 CC73FSL1H471J CHIP C 470PF J
C93 CK73FB1H103K CHIP C 0.010UF K
C94 CK73FB1H102K CHIP C 1000PF K
C95 CC73FCH1H470J CHIP C 47PF J
C96 CC73FSL1H101J CHIP C 100PF J
CN1 E40-4609-05 PIN ASSY
601 1B ✽ A01-3567-11 METALLIC CABINET
603 2A A22-1772-01 SUB PANEL
604 1A,1B A50-1303-02 SIDE PLATE
605 2A ✽ A60-1366-02 PANEL E
605 2A ✽ A60-1374-02 PANEL T
606 1A A09-0374-08 BATTERY COVER
607 1A ✽ A70-1155-05 REMOTE CONTROLLER ASSY
612 2A B07-2362-03 ESCUTCHEON
613 2A B10-2369-03 FRONT GLASS
614 2A B12-0317-04 INDICATOR
- B46-0310-03 WARRANTY CARD
- B58-1562-04 CAUTION CARD (P1,PRA,A5,1)
- ✽ B60-3715-00 INSTRUCTION MANUAL(ENGLISH) T
- ✽ B60-3716-00 INSTRUCTION MANUAL(FRENCH) E
- ✽ B60-3717-00 INSTRUCTION MANUAL(DUTCH) E
- ✽ B60-3718-00 INSTRUCTION MANUAL(GERMAN) E
- ✽ B60-3719-00 INSTRUCTION MANUAL(ITALIAN) E
- ✽ B60-3720-00 INSTRUCTION MANUAL(SPANISH) E
618 1C E30-2592-15 AC POWER CORD E
618 1C E30-2721-05 AC POWER CORD T
619 1B E35-1944-05 FLAT CABLE
620 1A E30-0615-05 AUDIO CORD
622 1A E30-2628-05 CORD WITH CONNECTOR
627 2A G11-2325-14 CUSHION
628 2A G11-2352-04 CUSHION
629 1B G11-2353-04 CUSHION
- H10-7351-02 POLYSTYRENE FOAMED FIXTURE
- ✽ H10-7352-12 POLYSTYRENE FOAMED FIXTURE
- ✽ H12-2358-04 PACKING FIXTURE T
- H25-1579-04 PROTECTION BAG E
- H25-1581-04 PROTECTION BAG T
- H25-1595-04 PROTECTION BAG
- ✽ H50-2493-04 ITEM CARTON CASE E
- ✽ H50-2852-04 ITEM CARTON CASE T
632 2C J02-0370-05 FOOT
633 2B ✽ J19-5877-05 UNIT HOLDER
634 1A J19-3645-05 ANTENNA STAND
635 1B J19-5878-05 UNIT HOLDER
636 1C J42-0083-05 POWER CORD BUSHING
638 1B,1C ✽ J19-5916-05 UNIT HOLDER
- J61-0307-05 WIRE BAND
641 2A K29-6738-04 KNOB(VOLUME)
642 2A K29-6739-04 KNOB(MULTI)
643 2A K29-6741-04 KNOB(POWER)
644 2B K29-6751-04 KNOB(EX BASS)
648 2C ✽ L07-2544-05 POWER TRANSFORMER
652 1A T90-0806-05 LEAD WIRE ANTENNA
653 1A T90-0820-05 LOOP ANTENNA
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
1 2
R-SE9/SE9T
TUNER UNIT(X05-4622-71)
R-SE9/SE9T(K) 1P 98.4.25 14:46 y[W 15
