Kenwood R-SE9T Service Manual

21
R-SE9/SE9T
PARTS LIST
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
R59 RK73FB2A222J CHIP R 2.2K J 1/10W
R67 RK73FB2A104J CHIP R 100K J 1/10W
R80 RK73EB2B102J CHIP R 1.0K J 1/8W
R81 -83 RK73FB2A102J CHIP R 1.0K J 1/10W
R84 RK73FB2A103J CHIP R 10K J 1/10W
R85 -88 RK73FB2A102J CHIP R 1.0K J 1/10W
R89 RD14NB2E101J RD 100 J 1/4W
R90 RK73FB2A562J CHIP R 5.6K J 1/10W
R91 RK73FB2A222J CHIP R 2.2K J 1/10W
R92 RK73FB2A123J CHIP R 12K J 1/10W
R93 RK73FB2A122J CHIP R 1.2K J 1/10W
R94 RD14NB2E561J RD 560 J 1/4W
R101,102 RK73FB2A102J CHIP R 1.0K J 1/10W
R103 RK73FB2A821J CHIP R 820 J 1/10W
R104 RK73FB2A473J CHIP R 47K J 1/10W
R105 RK73FB2A103J CHIP R 10K J 1/10W
W51 -54 R92-0670-05 CHIP R 0 OHM
W56 -58 R92-0679-05 CHIP R 0 OHM
W59 -61 R92-0670-05 CHIP R 0 OHM
W62 -67 R92-0679-05 CHIP R 0 OHM
W69 -71 R92-0679-05 CHIP R 0 OHM
W80 R92-0670-05 CHIP R 0 OHM
W81 R92-0679-05 CHIP R 0 OHM
W83 ,84 R92-0679-05 CHIP R 0 OHM
D1 HSS104 DIODE
D1 1SS133 DIODE
D31 MTZJ8.2(B) ZENER DIODE
D31 UZ-8.2BSB ZENER DIODE
D32 MA111 DIODE
D33 HSS104 DIODE
D33 1SS133 DIODE
D61 ,62 HSS104 DIODE
D61 ,62 1SS133 DIODE
D81 MTZJ5.1(B) ZENER DIODE
D81 UZ-5.1BSB ZENER DIODE
D101 MTZJ3.3(B) ZENER DIODE
D101 UZ-3.3BSB ZENER DIODE
IC1 LA1836 ANALOGUE IC
IC2 LC72131 MOS-IC
IC3 M5223FP IC(OP AMP X4)
Q1 ,2 2SC2714(R,O) TRANSISTOR
Q3 2SA1586(Y,GR) TRANSISTOR
Q3 2SA1611(M5,M6) TRANSISTOR
Q31 ,32 2SC4116(Y,GR) TRANSISTOR
Q31 ,32 2SC4177(L5,L6) TRANSISTOR
Q81 2SA1586(Y,GR) TRANSISTOR
Q81 2SA1611(M5,M6) TRANSISTOR
Q101,102 2SD1757K TRANSISTOR
Q103 2SA1586(Y,GR) TRANSISTOR
Q103 2SA1611(M5,M6) TRANSISTOR
A1 ✽ W02-2565-05 FM FRONT-END ASSY
C1 -12 CC73FCH1H221J CHIP C 220PF J
CN2 E40-4871-05 PIN ASSY
J1 E20-0321-05 LOCK TERMINAL BOARD(2P,F)
CF1 ,2 L72-0536-05 CERAMIC FILTER
L31 ✽ L30-0929-05 FM IFT
L32 ✽ L30-0930-05 FM IFT
L33 L30-0911-05 AM IFT
L34 ✽ L79-1237-05 LC FILTER
L35 ,36 ✽ L79-1236-05 LC FILTER
L61 L40-1091-17 SMALL FIXED INDUCTOR(1UH)
L62 L39-1348-05 COMBINATION COIL
L63 L40-1001-17 SMALL FIXED INDUCTOR(10UH,K)
L81 L40-1091-17 SMALL FIXED INDUCTOR(1UH)
X31 L78-0637-05 RESONATOR (456KHZ)
X81 L77-2185-05 CRYSTAL RESONATOR
R1 RD14NB2E101J RD 100 J 1/4W
R2 RK73EB2B221J CHIP R 220 J 1/8W
R3 RK73FB2A332J CHIP R 3.3K J 1/10W
R4 RK73FB2A681J CHIP R 680 J 1/10W
R5 RK73FB2A331J CHIP R 330 J 1/10W
R6 RK73FB2A220J CHIP R 22 J 1/10W
R7 RK73FB2A332J CHIP R 3.3K J 1/10W
R8 RK73FB2A331J CHIP R 330 J 1/10W
R10 RK73FB2A332J CHIP R 3.3K J 1/10W
R11 RK73FB2A681J CHIP R 680 J 1/10W
R12 RK73FB2A122J CHIP R 1.2K J 1/10W
R13 ,14 RK73FB2A331J CHIP R 330 J 1/10W
R15 RK73FB2A101J CHIP R 100 J 1/10W
R16 RK73FB2A220J CHIP R 22 J 1/10W
R17 RK73FB2A621J CHIP R 620 J 1/10W
R18 RK73FB2A123J CHIP R 12K J 1/10W
R19 RK73FB2A4R7J CHIP R 4.7 J 1/10W
R20 RK73FB2A122J CHIP R 1.2K J 1/10W
R31 RS14KB3A820J FL-PROOF RS 82 J 1W
R32 RK73EB2B562J CHIP R 5.6K J 1/8W
R33 RK73FB2A302J CHIP R 3.0K J 1/10W
R34 RK73FB2A822J CHIP R 8.2K J 1/10W
R35 RK73FB2A333J CHIP R 33K J 1/10W
R36 RK73FB2A393J CHIP R 39K J 1/10W
R37 RK73FB2A272J CHIP R 2.7K J 1/10W
R38 RK73FB2A333J CHIP R 33K J 1/10W
R39 RK73FB2A223J CHIP R 22K J 1/10W
R40 RK73FB2A332J CHIP R 3.3K J 1/10W
R41 RK73FB2A222J CHIP R 2.2K J 1/10W
R42 RK73FB2A473J CHIP R 47K J 1/10W
R43 ,44 RK73FB2A332J CHIP R 3.3K J 1/10W
R45 ,46 RK73FB2A122J CHIP R 1.2K J 1/10W
R47 ,48 RK73FB2A392J CHIP R 3.9K J 1/10W
R49 RK73FB2A473J CHIP R 47K J 1/10W
R51 RK73FB2A102J CHIP R 1.0K J 1/10W
R52 RK73FB2A104J CHIP R 100K J 1/10W
R53 RK73FB2A102J CHIP R 1.0K J 1/10W
R54 RK73FB2A683J CHIP R 68K J 1/10W
R55 RK73FB2A473J CHIP R 47K J 1/10W
R56 RK73FB2A104J CHIP R 100K J 1/10W
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
3 4
AUDIO UNIT(X09-4952-70)
R-SE9/SE9T(K) 1P 98.4.25 14:46 y[W 11
