22
R-SE9/SE9T
PARTS LIST
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
C150 CK73FB1H103K CHIP C 0.010UF K
C151 CC73FCH1H221J CHIP C 220PF J
C152 CE04KW1A221M ELECTRO 220UF 10WV
C153 C90-3230-05 ELECTRO 100UF 16WV
C154 CE04KW1V220M ELECTRO 22UF 35WV
CN1 E40-4807-05 PIN ASSY
CN2 ,3 E40-4607-05 PIN ASSY
CN4 E40-3246-05 PIN ASSY
CN5 E40-4922-05 FLAT CABLE CONNECTOR
CN6 E40-3246-05 PIN ASSY
CN9 ,10 E40-4871-05 PIN ASSY
CN11 E40-4632-05 PIN ASSY
J1 E63-0116-05 PHONO JACK
J2 E63-1033-05 PHONO JACK
J3 E63-1034-05 PHONO JACK
J4 E70-0034-05 LOCK TERMINAL BOARD
J5 E08-0312-05 RECTANGULAR RECEPTACLE
J6 ✽ E63-1033-05 PHONO JACK
J7 ✽ E63-1034-05 PHONO JACK
667 F09-0138-05 FAN
- F29-0112-05 INSULATING WASHER
F1 F06-1022-05 FUSE (SEMKO) (250V T1AL)
CN12,13 J13-0075-05 FUSE CLIP
R1 ,2 RK73FB2A102J CHIP R 1.0K J 1/10W
R3 ,4 RK73FB2A683J CHIP R 68K J 1/10W
R5 ,6 RK73FB2A102J CHIP R 1.0K J 1/10W
R7 ,8 RK73FB2A683J CHIP R 68K J 1/10W
R9 ,10 RK73FB2A102J CHIP R 1.0K J 1/10W
R11 ,12 RK73FB2A104J CHIP R 100K J 1/10W
R13 ,14 RK73FB2A102J CHIP R 1.0K J 1/10W
R15 ,16 RK73FB2A683J CHIP R 68K J 1/10W
R17 ,18 RK73FB2A102J CHIP R 1.0K J 1/10W
R19 ,20 RK73FB2A104J CHIP R 100K J 1/10W
R21 ,22 RK73FB2A102J CHIP R 1.0K J 1/10W
R23 ,24 RK73FB2A683J CHIP R 68K J 1/10W
R25 ,26 RK73FB2A224J CHIP R 220K J 1/10W
R27 ,28 RK73FB2A330J CHIP R 33 J 1/10W
R29 ,30 RK73FB2A103J CHIP R 10K J 1/10W
R31 ,32 RK73FB2A272J CHIP R 2.7K J 1/10W
R33 ,34 RK73FB2A562J CHIP R 5.6K J 1/10W
R35 ,36 RK73FB2A223J CHIP R 22K J 1/10W
R37 -40 RK73FB2A222J CHIP R 2.2K J 1/10W
R41 ,42 RK73FB2A473J CHIP R 47K J 1/10W
R43 ,44 RK73FB2A222J CHIP R 2.2K J 1/10W
R45 ,46 RK73FB2A102J CHIP R 1.0K J 1/10W
R47 ,48 RK73FB2A473J CHIP R 47K J 1/10W
R49 ,50 RK73FB2A102J CHIP R 1.0K J 1/10W
R52 RK73FB2A393J CHIP R 39K J 1/10W
R53 ,54 RK73FB2A911J CHIP R 910 J 1/10W
R55 ,56 RK73FB2A393J CHIP R 39K J 1/10W
R59 ,60 RK73FB2A103J CHIP R 10K J 1/10W
R65 -68 RK73FB2A471J CHIP R 470 J 1/10W
R75 ,76 RD14NB2E181J RD 180 J 1/4W
C13 ,14 CE04KW1E100M ELECTRO 10UF 25WV
C15 ,16 CC73FCH1H221J CHIP C 220PF J
C17 ,18 CE04KW1E100M ELECTRO 10UF 25WV
C19 ,20 CE04KW1H010M ELECTRO 1.0UF 50WV
C21 ,22 CK73FB1H562K CHIP C 5600PF K
C23 -30 CK73FB1C154K CHIP C 0.15UF K
C31 ,32 C90-3224-05 ELECTRO 4.7UF 16WV
C33 ,34 C90-3240-05 ELECTRO 2.2UF 35WV
C35 ,36 CC73FCH1H221J CHIP C 220PF J
C37 ,38 CC73FCH1H102J CHIP C 1000PF J
C39 ,40 C90-3211-05 ELECTRO 33UF 6.3WV
C41 ,42 C90-3215-05 ELECTRO 220UF 6.3WV
C43 ,44 CK73FB1H152K CHIP C 1500PF K
C45 ,46 CE04KW1H100M ELECTRO 10UF 50WV
C47 ,48 CC73FCH1H102J CHIP C 1000PF J
C49 -52 CK73FF1E104Z CHIP C 0.10UF Z
C53 ,54 CK73FB1H472K CHIP C 4700PF K
C55 ,56 CC73FCH1H070D CHIP C 7.0PF D
C57 -60 CC73FCH1H470J CHIP C 47PF J
C61 -68 CC73FCH1H101J CHIP C 100PF J
C101,102 ✽ C90-3774-05 ELECTRO 4700UF 50V
C103 CK45FE2H103P CERAMIC 0.010UF P
C104 CK73FB1H103K CHIP C 0.010UF K
C105 CE04KW1V101M ELECTRO 100UF 35WV
C106 CE04KW1H470M ELECTRO 47UF 50WV
C107 CE04KW1V220M ELECTRO 22UF 35WV
C108 CE04KW1E101M ELECTRO 100UF 25WV
C109 CE04KW1H100M ELECTRO 10UF 50WV
C110 CE04KW1E100M ELECTRO 10UF 25WV
C111 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C112 CE04KW1V102M ELECTRO 1000UF 35WV
C113 CE04KW1V221M ELECTRO 220UF 35WV
C114,115 CE04KW1V470M ELECTRO 47UF 35WV
C116-118 CK73FB1H102K CHIP C 1000PF K
C119 CK73FB1H103K CHIP C 0.010UF K
C121 CE04KW1H100M ELECTRO 10UF 50WV
C122,123 CE04KW1C470M ELECTRO 47UF 16WV
C124,125 CC73FSL1H221J CHIP C 220PF J
C126,127 CK73FB1H103K CHIP C 0.010UF K
C128 CC73FSL1H471J CHIP C 470PF J
C129,130 CC73FSL1H221J CHIP C 220PF J
C131 CC73FCH1H101J CHIP C 100PF J
C132,133 CK73FB1H103K CHIP C 0.010UF K
C134 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C135 CE04KW1H010M ELECTRO 1.0UF 50WV
C136 CK73FB1H103K CHIP C 0.010UF K
C137,138 CC73FSL1H221J CHIP C 220PF J
C140 CE04KW1C100M ELECTRO 10UF 16WV
C141 C90-3225-05 ELECTRO 10UF 16WV
C142 CE04HW1E100M NP-ELEC 10UF 25WV
C143 CE04HW1H010M NP-ELEC 1.0UF 50WV
C144,145 CE04KW1C100M ELECTRO 10UF 16WV
C146 C90-3212-05 ELECTRO 47UF 6.3WV
C147,148 C90-3225-05 ELECTRO 10UF 16WV
C149 CC73FCH1H101J CHIP C 100PF J
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
5 6
R-SE9/SE9T(K) 1P 98.4.25 14:46 y[W 9
