Kenwood R-SE9T Service Manual

R-SE9/SE9T
23
PARTS LIST
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
D23 RD4.7ES(B) ZENER DIODE
D24 -27 S5688B DIODE
D24 -27 1SR139-400 DIODE
D28 HSS104 DIODE
D28 1SS133 DIODE
D29 D5SBA20F03 DIODE
D29 RBV-602LFA DIODE
D30 -32 S5688B DIODE
D30 -32 1SR139-400 DIODE
D33 ,34 MTZJ16(B) ZENER DIODE
D33 ,34 RD16ES(B) ZENER DIODE
D35 ,36 HSS104 DIODE
D35 ,36 1SS133 DIODE
D37 ,38 S5688B DIODE
D37 ,38 1SR139-400 DIODE
D39 MTZJ6.2(B) ZENER DIODE
D39 RD6.2ES(B) ZENER DIODE
D40 ,41 MTZJ5.1(B) ZENER DIODE
D40 ,41 RD5.1ES(B) ZENER DIODE
D42 MTZJ6.2(B) ZENER DIODE
D42 RD6.2ES(B) ZENER DIODE
D44 ,45 MTZJ4.7(B) ZENER DIODE
D44 ,45 RD4.7ES(B) ZENER DIODE
D46 MTZJ3.9(B) ZENER DIODE
D46 RD3.9ES(B) ZENER DIODE
D47 ,48 HSS104 DIODE
D47 ,48 1SS133 DIODE
D49 MTZJ4.7(B) ZENER DIODE
D49 RD4.7ES(B) ZENER DIODE
D50 MTZJ6.2(B) ZENER DIODE
D50 RD6.2ES(B) ZENER DIODE
D51 HSS104 DIODE
D51 1SS133 DIODE
IC1 NJU7313AM ANALOGUE IC
IC2 NJM4565D-D IC(OP AMP X2)
IC3 TDA7319 ANALOGUE IC
IC4 NJM4565D-D IC(OP AMP X2)
IC5 NJM4565L-D ANALOGUE IC
Q1 -4 2SC2878(B) TRANSISTOR
Q5 ,6 2SC1845(F,E) TRANSISTOR
Q7 -10 2SA992(F,E) TRANSISTOR
Q11 ,12 2SC1845(F,E) TRANSISTOR
Q13 ,14 TRAITR2N TRANSISTOR
Q15 ,16 TRAITR2P TRANSISTOR
Q17 ,18 2SC1845(F,E) TRANSISTOR
Q31 ,32 2SC2458(Y,GR) TRANSISTOR
Q31 ,32 2SC3311A(Q,R) TRANSISTOR
Q33 ,34 2SC4097(Q,R) TRANSISTOR
Q35 2SA992(F,E) TRANSISTOR
Q36 2SC4097(Q,R) TRANSISTOR
Q37 2SB1640 TRANSISTOR
Q38 2SC4116(Y,GR) TRANSISTOR
Q38 2SC4177(L5,L6) TRANSISTOR
Q39 2SC4097(Q,R) TRANSISTOR
Q40 2SA1534A(R,S) TRANSISTOR
R77 -82 RK73FB2A561J CHIP R 560 J 1/10W
R83 ,84 RD14NB2E181J RD 180 J 1/4W
R87 -90 RD14NB2E4R7J RD 4.7 J 1/4W
R91 ,92 RK73FB2A431J CHIP R 430 J 1/10W
R96 RK73FB2A102J CHIP R 1.0K J 1/10W
R101,102 RK73FB2A512J CHIP R 5.1K J 1/10W
R107,108 RS14KB3D4R7J FL-PROOF RS 4.7 J 2W
R152 RD14NB2E560J RD 56 J 1/4W
R154 RD14BB2E102J RD 1.0K J 1/4W
R155 RD14NB2E222J RD 2.2K J 1/4W
R159 RD14NB2E3R3J RD 3.3 J 1/4W
R160 RD14NB2E2R2J RD 2.2 J 1/4W
R166 RK73FB2A163J CHIP R 16K J 1/10W
R167 RK73FB2A153J CHIP R 15K J 1/10W
R168,169 RK73FB2A104J CHIP R 100K J 1/10W
R170 RK73FB2A102J CHIP R 1.0K J 1/10W
R174 RS14KB3A821J FL-PROOF RS 820 J 1W
R176 RK73FB2A103J CHIP R 10K J 1/10W
R177 RD14NB2E470J RD 47 J 1/4W
R180 RK73FB2A103J CHIP R 10K J 1/10W
R181 RD14NB2E470J RD 47 J 1/4W
R182 RK73FB2A103J CHIP R 10K J 1/10W
R184 RK73FB2A243J CHIP R 24K J 1/10W
R185 RK73FB2A103J CHIP R 10K J 1/10W
R187 RD14NB2E470J RD 47 J 1/4W
R189,190 RK73FB2A102J CHIP R 1.0K J 1/10W
R191 RD14NB2E151J RD 150 J 1/4W
R192 RK73FB2A473J CHIP R 47K J 1/10W
R193 RK73FB2A104J CHIP R 100K J 1/10W
R194 RK73FB2A224J CHIP R 220K J 1/10W
R195 RK73FB2A332J CHIP R 3.3K J 1/10W
R196 RK73FB2A473J CHIP R 47K J 1/10W
R197 RK73FB2A103J CHIP R 10K J 1/10W
R199 RK73FB2A222J CHIP R 2.2K J 1/10W
R204 RK73FB2A103J CHIP R 10K J 1/10W
R207 RK73FB2A474J CHIP R 470K J 1/10W
R208 RK73FB2A623J CHIP R 62K J 1/10W
R212 RK73FB2A104J CHIP R 100K J 1/10W
R213 RK73FB2A222J CHIP R 2.2K J 1/10W
R214 RK73FB2A103J CHIP R 10K J 1/10W
VR1 ,2 R12-0607-05 TRIMMING POT
W201-207 R92-0670-05 CHIP R 0 OHM
W211,212 R92-0679-05 CHIP R 0 OHM
W213 R92-0670-05 CHIP R 0 OHM
W214 R92-0679-05 CHIP R 0 OHM
K1 S76-0058-05 MAGNETIC RELAY
K2 ,3 S76-0056-05 MAGNETIC RELAY
TS1 S79-0020-05 THERMAL SWITCH
D1 -16 HSS104 DIODE
D1 -16 1SS133 DIODE
D21 HSS104 DIODE
D21 1SS133 DIODE
D22 MA111 DIODE
D23 MTZJ4.7(B) ZENER DIODE
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
L : Scandinavia K : USA P : Canada R : Mexico C : China
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany
Y : AAFES(Europe) X : Australia I : Malaysia V : China (Shanghai)
Q : Russia H : Korea M : Other Areas indicates safety critical components.
7 8
R-SE9/SE9T(K) 1P 98.4.25 14:46 y[W 8
