Kenwood VR-7070 User Manual

14
EN
DVD/6CH INPUT
FRONT SURROUND
SUB
WOOFER
CENTER
PLAY INPLAY IN
DVD MONITOR
VIDEO 2 VIDEO 3
S VIDEO
IN
VIDEO
S VIDEO
IN
VIDEO
S VIDEO
IN
VIDEO
ROOM B
OUT
S VIDEO
OUT
VIDEO
DVD MONITOR
OUT
VIDEO
IN
VIDEO
IN
VIDEO
IN
VIDEO
IN
VIDEO
OUT
VIDEO
COAXIAL OPTICAL OPTICAL
VIDEO 3
OPTICAL
MONITORCD/DVD
DIGITAL IN DIGITAL OUT
DVD/
6CH
VIDEO
2
Connecting a DVD player (6-channel input)
If you have connected a DVD player to the receiver with digital connection, be sure to read the “Input mode settings” section carefully. 8
FRONT
OUT L/R
S VIDEO
OUT
COAXIAL
DIGITAL OUT
(AUDIO)
DVD player
S VIDEO cord
SURROUND
OUT L/R
VIDEO OUT
(Yellow RCA
pin cord)
CENTER
OUT
SUBWOOFER
OUT
Setting up the system

Kenwood VR-7070 Specifications

General

Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Input sensitivity (MM)	2.5 mV
Signal to noise ratio (MM)	80 dB
Digital inputs	coaxial, optical
Video Connections	Composite, S-Video
Power Output	100 watts per channel
Tuning range	FM, AM
Speaker load impedance	8 ohms
Dimensions (metric)	440 x 162 x 439 mm
