For future reference, please record the serial number of your
cooktop here:
STEP #2
Check the Electrical Supply Requirements
This product must be installed in accordance with national, state and local electric codes. The
following table provides the correct voltage, amperage and frequency that must be supplied to the
cooktop.
The supply must be from an individual grounded circuit that is protected by a circuit breaker and
rated per the specications for the various models as shown in the table above.
Max Connected Required Power Minimum
Kenyon Part # Model # Load Supply Input Wire Size
B41540 Med2QTCP 2600 Watts 120VAC/22A/50/60Hz #12 AWG
B41549 Med2QTCP 3000 Watts 208VAC/14.5A/50/60Hz #12 AWG
B41541 Med2QTCP 3000 Watts 240VAC/12.5A/50/60Hz #12 AWG
B41540L Med2QTCL 2600 Watts 120VAC/22A/50/60Hz #12 AWG
B41549L Med2QTCL 3000 Watts 208VAC/14.5A/50/60Hz #12 AWG
B41541L Med2QTCL 3000 Watts 240VAC/12.5A/50/60Hz #12 AWG
B41575 & B41775 Med2QTCTP 2400 Watts 120VAC/20A/50/60Hz #12 AWG
B41579 & B41779 Med2QTCTP 2400 Watts 208VAC/11.5A/50/60Hz #12AWG
B41576 & B41776 Med2QTCTP 2400 Watts 240VAC/10A/50/60Hz #12 AWG
B41575L & B41775L Med2QTCTL 2400 Watts 120VAC/20A/50/60Hz #12 AWG
B41579L & B41779L Med2QTCTL 2400 Watts 208VAC/11.5A/50/60Hz #12 AWG
B41576L & B41776L Med2QTCTL 2400 Watts 240VAC/10A/50/60Hz #12 AWG
STEP #3
Countertop Preparation
Please read this section prior to making cutout for cooktop.
It is important to plan ahead for installation of the cooktop, keeping the following dimensions in
mind (please refer to Figure A).
Warning: If the electric power supply does not meet the product
specications, consult with a licensed electrician before proceeding
with installation.
!
6
