N° Components N° Components
1 Wirnet™ iFemtoCell-evoluon 9 SMA connector for LoRa antenna
2 Silkscreened KERLINK marking 10 Reset push buon
3
Jack connector (for power supply 12Vdc
0,5A)
11 Silkscreened Reset marking
4 USB-A connector for conguraon 12 USIM connector
5 RJ45 connector (Ethernet) 13
USB-C connector for debug probe and for
conguraon
6 3 bicolor LEDs 14
LoRa antenna (862-873MHz, 902-928MHZ, 3dBi,
50Ω; vercal polarizaon)
7 Wall mounng oblong holes 15 AC/DC power supply (not provided)
8 Scker with markings 16 Quick Start Guide (this document)
