Kernau KGH 6422 CI X User Manual

EN
38

• Theairrequiredforburningistakenfromtheenvironmentofthehobandtheburntgasesarereleased
toit.Properventilationshouldbemaintainedforsafeoperationoftheunit.Theventilationopenings
definedasperthevolumeoftheenvironmentareprovidedatthetable(Table1).
• Burntgasesshouldbedischargedoutsidebythehoodwithconnectiontoventilationshaft.
• Ifnokitchenhoodisused,anelectricalfanshouldbeinstalledatthewallorwindowofthebuilding
abletodischarge3-5timesofthekitchenair(Figure6).
1. Cooktop
2. Aspirator
3. Electricalventilator
4. VentilationOpening
 
Lessthan5m³ Minimum100cm²
Between5m³and10m³ Minimum50cm²
Largerthan10m³ Notrequred
BasementorCellar Minimum65cm²
Figure6.
