Kernel KN-5000C - Fuse Replacement

70
5.7 Fuses replacement
Figure 5-2 Figure 5-3 Figure 5-4
As shown in Figure 5-2, turn the fuse holder counterclockwise with a
screwdriver to remove the fuse (as shown in Figure 5-3). Replace it with a
new fuse and turn it clockwise into the fuse holder, as shown in Figure
5-4.
Warning!
⚫ Before replacing the fuse, turn off the power switch and
disconnect the power wire from the outlet.
